Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CrMo 4, Columbus Zona, double butted
Suspension Fork
Columbus Futura Cross+, Carbon, 12 x 100 mm, Flatmount, tapered,
Drivetrain
Rear Derailleur
N.V.
Shift Levers
Campagnolo Ekar, 13-speed, Clutch lock
Cassette
Campagnolo Ekar, 13-speed, 10-44 teeth, N3W freewheel body
Crank
Campagnolo Ekar, Carbon, 40 teeth, (170 / 172,5 / 172,5 / 175 / 175 mm)
Chain
Campagnolo Ekar, 13-speed
Chain Guide
N.V.
Pedals
N.V.
Wheels
Front Hub
Campagnolo Shamal Carbon, 12 x 100 mm, Disc, 24 holes
Rear Hub
Campagnolo Shamal Carbon, 12 x 142 mm, Disc, 24 holes, N3W
Rims
Campagnolo Ekar, Carbon, 40 teeth, (170 / 172,5 / 172,5 / 175 / 175 mm)
Spokes
Campagnolo Shamal Carbon
Tires
Schwalbe G-One R, 45-622
Brakes
Brakes
Campagnolo Ekar (front 160 mm / rear 160 mm), Flatmount Disc brake
Brake Levers
Campagnolo Ekar, 13-speed, Ultra-Shift
Cockpit
Stem
Ritchey C-220 Matrix WCS Carbon, 6°, (70 / 70 / 70 / 90 / 90 mm)
Handlebar
Ritchey Venturemax WCS Carbon, Flare 24°, (420 / 440 / 440 / 460 / 460 mm)
Grips
Brooks Cambium, 3,0 mm thick, black
Seat
Saddle
Brooks Carved C13, Carbon-rail, 145 mm wide, black
Seatpost
Ritchey WCS Carbon Link Flexilogic, 27,2 mm, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
