Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset CUES, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CroMo 4
Suspension Fork
28" CroMo,
Drivetrain
Rear Derailleur
Shimano Cues FD-U6010, 2-speed
Shift Levers
Shimano Cues RD-U6020, 10-speed
Cassette
Shimano Cues CS-LG300, 10-speed, 11-39 teeth
Crank
Shimano Cues FC-U6000-2, 170 mm, Hollotech II, 46/30 teeth
Chain
Shimano CN-LG500
Chain Guide
Horn Catena 05/3, chain guard
Pedals
Marwi SP-823, black
Wheels
Front Hub
Shutter Precission PV-8, hub dynamo, 36 holes
Rear Hub
Shimano FH-QC400-HM, 36 holes
Rims
Shimano Cues FC-U6000-2, 170 mm, Hollotech II, 46/30 teeth
Spokes
Niro 2,0 mm
Tires
Schwalbe Marathon, 40-622, reflex
Brakes
Brakes
Magura HS22, including Brakebooster rim brake
Brake Levers
Magura HS22
Cockpit
Stem
Humpert Ergotec Octopus, 31,8 mm, angle adjustable, safety level 4
Handlebar
Humpert Ergotec MAS Trekking, 660 mm, safety level 4
Grips
Herrmans Grit D33, with clamp
Seat
Saddle
Selle Royal Ariel
Seatpost
Humpert Ergotec Atar, patent, aluminum, 27.2 mm, 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 57cm | 62cm | 45cm | 50cm | 55cm | 60cm |
|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
