Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset CUES, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CrMo 4, double butted
Suspension Fork
28" aluminum, thru-axle 12 x 100 mm,
Drivetrain
Rear Derailleur
Shimano Cues FD-U8010, 2-speed
Shift Levers
Shimano Cues RD-U8020, 11-speed
Cassette
Shimano Cues CS-LG400, 11-speed, 11-45 teeth
Crank
Shimano Cues FC-U8000-2, 170 mm, Hollotech II, 46/32 teeth
Chain
Shimano CN-LG500
Chain Guide
Shimano chain guard
Pedals
Marwi SP-823, black
Wheels
Front Hub
Shutter Precission PL-7, 12 x 100 mm, hub dynamo, Centerlock, 36 holes
Rear Hub
Shimano Deore XT FH-M8000, Centerlock, 36 holes
Rims
Shimano Cues FC-U8000-2, 170 mm, Hollotech II, 46/32 teeth
Spokes
Niro 2,0 mm
Tires
Schwalbe Marathon, 47-622, reflex
Brakes
Brakes
Shimano Deore XT BR-M8100 (front 160 mm / rear 160 mm) disc
Brake Levers
Shimano Deore XT BL-T8100, 3-finger brake lever
Cockpit
Stem
Levelnine, aluminum, a-head, 31,8 mm
Handlebar
Levelnine, Trekking, aluminum, 640 mm
Grips
Ergon GP1, with clamp
Seat
Saddle
Selle Royal Essenza
Seatpost
Levelnine, patent, aluminum, 27,2 mm, 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 57cm | 62cm | 45cm | 50cm | 55cm | 60cm |
|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
