Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Gates CDX -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CrMo 4, double butted
Suspension Fork
27,5" 25CrMo 4,
Drivetrain
Shift Levers
Rohloff Speedhub, 14-speed
Cassette
Gates CDX, 20 teeth
Crank
Gates S550, Aluminum, 170 mm, Gates CDX 55 teeth with chain guard
Chain
Gates CDX-drive belt
Chain Guide
Gates chain guard
Pedals
VP-196 Aluminum
Wheels
Front Hub
SON 28, 12 x 100 mm, hub dynamo, Centerlock, 32 holes
Rear Hub
Rohloff Speedhub 14 speed, Disc, 32 holes
Rims
Gates S550, Aluminum, 170 mm, Gates CDX 55 teeth with chain guard
Spokes
Niro ED 2,34 mm
Tires
Schwalbe Marathon Mondial, 50-584, reflex
Brakes
Brakes
Shimano Deore XT BR-M8100 (front 203 mm / rear 203 mm) disc brake
Brake Levers
Shimano Deore XT BL-T8100, 3-finger-brake lever
Cockpit
Stem
Humpert Ergotec Piranha 2, 31,8 mm, safety level 6
Handlebar
Humpert Ergotec Trekking, Aluminum, 620 mm, safety level 6
Grips
Ergon GP3, with clamp and integrated Barends
Seat
Saddle
Ergon ST Core Prime
Seatpost
Humpert Ergotec Skalar, patent, aluminum, 27.2 x 400 mm, safety level 6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 57cm | 62cm |
|---|---|---|---|
| Wheels | 650 | 650 | 650 |
