Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset CUES, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
25 CrMo 4, double butted
Suspension Fork
26" 25CrMo 4,
Drivetrain
Rear Derailleur
Shimano Cues FD-U8010, 2-speed
Shift Levers
Shimano Cues RD-U6020-11, 11-speed
Cassette
Shimano Cues CS-LG400, 11-speed, 11-45 teeth
Crank
Shimano Cues FC-U6010-2, 170 mm, Hollowtec II, 46/32 teeth
Chain
Shimano CN-LG500
Chain Guide
Shimano chain guard
Pedals
VP-196 aluminum
Wheels
Front Hub
Shutter Precission PV-8, hub dynamo, 36 holes
Rear Hub
Shimano FH-QC400-HM, 36 holes
Rims
Shimano Cues FC-U6010-2, 170 mm, Hollowtec II, 46/32 teeth
Spokes
Niro ED 2,34 mm
Tires
Schwalbe Marathon Mondial, 50-559, reflex
Brakes
Brakes
Magura HS33, including Brakebooster rim brake
Brake Levers
Magura HS33
Cockpit
Stem
Humpert Ergotec Piranha 2, 31,8 mm, safety level 6
Handlebar
Humpert Ergotec Trekking, aluminum, 620 mm, safety level 6
Grips
Ergon GP3, with clamp and integrated Barends
Seat
Saddle
Selle Royal Scientia
Seatpost
Humpert Ergotec Skalar, patent, aluminum, 27.2 mm, 400 mm, safety level 6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 52cm | 57cm | 45cm | 50cm |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
