Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Travel Front 100mm -
Suspension Hardtail -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% 4130 chromoly DJ frame, 3/8" Dropout, Threaded 73mm BB, Disc Mount
Suspension Fork
Fairdale Hareraiser Chromoly, 100mm spacing with 15mm thru axle
Drivetrain
Crank
19mm 8-Spline, 170mm
Bottom Bracket
Euro
Chain
KMC Z1eHX
Pedals
Odyssey Twisted Pro PC
Wheels
Front Hub
Sealed 15mm Thru Axle
Rear Hub
Sealed Cassette, 3/8" Axle, Disc
Rims
26" 32H
Tires
Maxxis DTH 2.3"
Brakes
Brakes
Mechanical Disc
Brake Levers
Odyssey Monolever
Cockpit
Stem
Sunday Freeze, 48mm Front Load
Handlebar
Fairdale MX-4
Grips
Fairdale Swan
Headset
FSA Orbit Sealed
Seat
Saddle
Odyssey Big Stitch, Pivotal
Seatpost
Pivotal 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | SM/MD | MD/LG | MD/LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.373 mm | 1.316 mm | 1.295 mm | 1.241 mm |
| Bottom Bracket Height | 323 mm | 315 mm | 323 mm | 315 mm |
| Rake | 40 mm | 30 mm | 40 mm | 30 mm |
| Stack | 570 mm | 562 mm | 570 mm | 561 mm |
| Reach | 415 mm | 427 mm | 440 mm | 452 mm |
| Top Tube Length | 600 mm | 600 mm | 625 mm | 625 mm |
| Seat Tube Angle | 72 ° | 73 ° | 72 ° | 73 ° |
| Seat Tube Length | 340 mm | 340 mm | 340 mm | 340 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 69.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 379 mm | 379 mm | 379 mm | 379 mm |
| Bottom Bracket Drop | 20 mm | 28 mm | 20 mm | 28 mm |
| Standover Height | 690 mm | 681 mm | 690 mm | 678 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | mm |
| Wheels | 26" | 26" | 26" | 26" |
