Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset SX Eagle -
Suspension Hardtail -
Motor Yamaha 75Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium frame. Sizes: S-M-L
Suspension Fork
Suntour XCR34, travel 100mm
Drivetrain
Rear Derailleur
SRAM SX Eagle
Cassette
SRAM SX, 12V, 11-50
Chain
SRAM SX
Pedals
Aluminium
Wheels
Front Hub
GBC, 110mm Boost
Rear Hub
GBC, 148mm Boost
Rims
GBC 29"
Tires
Vittoria E-Randonneur
Brakes
Brakes
Front: Promax Solve ST 925 hydraulic 2P, 180mm disc, Rear: Promax Solve ST 925 hydraulic 2P, 180mm disc
Cockpit
Stem
GBC 70mm
Handlebar
GBC 700mm, Rise 20mm
Grips
Urban Gist
Seat
Saddle
Selle Italia S5 Superflow
Seatpost
Promax Suspended Ø30.9
Motor & Battery
Motor
Yamaha PW S2, Torque/Coppia: 75Nm
Battery
Fantic, Lithium Ion, 36 Volt, 630Wh
Fit data
Geometry
