Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Travel Front 120mm -
Fork RockShox SID
-
Groupset GX Eagle AXS -
Suspension Full -
Motor TQ 50Nm hub-drive -
Battery TQ integrated, Lithium Ion, 360Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox SID 2P 120mm - remote lock
Rear Shock
RockShox SIDLuxe 2P - remote lock
Drivetrain
Rear Derailleur
SRAM GX AXS
Shift Levers
SRAM GX AXS
Cassette
SRAM GX, 12V, 10-52
Crank
SRAM 34t
Chain
SRAM GX
Wheels
Rims
Mavic Crossmax SL S 29"
Tires
Front: Pirelli SCORPION ProWall XC-RC - 29"x 2.2, Rear: Pirelli SCORPION ProWall XC-RC - 29"x 2.2
Brakes
Brakes
Magura MT8 PRO 2 Piston disc brake
Cockpit
Stem
nd /na
Handlebar
FANTIC RACING INTEGRATED FLAT-17°, 780mm
Seat
Saddle
Selle Italia Novus Boost X-Cross Superflow
Seatpost
Crankbrothers Highline 3 Ø30.9
Motor & Battery
Motor
TQ HPR-50, Torque/Coppia: 50 Nm
Battery
TQ integrated, Lithium Ion, 360Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
