Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Fork Suntour -
Groupset GX -
Suspension Full -
Motor TQ 50Nm hub-drive -
Battery TQ integrated, Lithium Ion, 360Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Suntour AXON34 LO-RC PCS
Rear Shock
Suntour EDGE PLUS 2CR
Drivetrain
Rear Derailleur
SRAM GX
Shift Levers
SRAM GX
Cassette
SRAM GX, 12V, 10-52
Crank
SRAM 34t
Chain
SRAM GX
Wheels
Rims
Mavic Crossmax SL S 29"
Tires
Front: Vittoria SYERRA - 29"x 2.4, Rear: Vittoria SYERRA - 29"x 2.4
Brakes
Brakes
Magura MT SPORT 2 Piston disc brake
Cockpit
Stem
GBC Ø31,8 x 70mm +8°
Handlebar
GBC Ø31,8 FLAT
Seat
Saddle
Selle Italia Model-X Superflow
Seatpost
Crankbrothers Highline 3 Ø30.9
Motor & Battery
Motor
TQ HPR-50, Torque/Coppia: 50 Nm
Battery
TQ integrated, Lithium Ion, 360Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
