Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 190mm -
Fork Suntour DUROLUX
-
Groupset GX Eagle -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
SUNTOUR DUROLUX-38 190mm
Rear Shock
RockShox SuperDeluxe Coil Select+
Drivetrain
Rear Derailleur
SRAM GX
Shift Levers
SRAM GX Eagle
Cassette
SRAM SX,12V, 11-50
Crank
SRAM 34t
Chain
SRAM NX
Wheels
Rims
MAVIC E-DEEMAX 29"- 27.5"
Tires
Vittoria E-MARTELLO 27,5"x 2.8
Brakes
Brakes
MAGURA MT7 4 Piston disc brake
Cockpit
Stem
FSA Gradient-35mm- Ø35 - Rise +6°
Handlebar
FSA Gradient-800mm- Ø35 - Rise 15mm
Seat
Saddle
Selle Italia MODEL-X BOW Superflow
Seatpost
Crankbrothers HIGHLIGHT7 Ø 30.9 S-M, L
Motor & Battery
Motor
Brose S-Mag 36, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 364 mm | 364 mm | 364 mm |
| Front Center | 767 mm | 797 mm | 822 mm |
| Reach | 414 mm | 443 mm | 469 mm |
| Top Tube Length | 590 mm | 620 mm | 650 |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1226 mm | 1256 mm | 1281 mm |
| Bottom Bracket Drop | -9 mm | -9 mm | -9 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
