Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Fork Suntour DUROLUX -
Groupset NX Eagle, GX -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 720Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Sizes: S - M - L
Suspension Fork
SUNTOUR Durolux 38
Rear Shock
RockShox SuperDeluxe Select+
Drivetrain
Rear Derailleur
SRAM GX
Shift Levers
SRAM NX Eagle
Cassette
SRAM SX, 12V, 11-50
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Fulcrum E-FIRE 700 29"-27.5"
Tires
Vittoria E-MARTELLO 27,5"x 2.6
Brakes
Brakes
SRAM Code R 4 Piston disc brake
Cockpit
Stem
FSA Grid-50mm- Ø35 - Rise +6°
Handlebar
FSA Grid-800mm- Ø35 - Rise 15mm
Seat
Saddle
Selle Italia X BOW Superflow
Seatpost
SWITCH SW Ø 30.9
Motor & Battery
Motor
Brose S-Mag 36, Torque/Coppia: 90 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 720Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 361.5 mm | 361.5 mm | 361.5 mm |
| Reach | 390.5 mm | 421.5 mm | 446 mm |
| Top Tube Length | 571.5 mm | 606 mm | 633 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 390 mm | 440 mm | 490 mm |
| Head Tube Angle | 64 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1195 mm | 1224 mm | 1246 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
