Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Fork RockShox 35 Gold RL
-
Groupset GX Eagle AXS -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 630Wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
RockShox 35 Gold RL - 29" 150mm
Rear Shock
RockShox Deluxe Select+
Drivetrain
Rear Derailleur
SRAM GX AXS
Shift Levers
SRAM GX AXS Eagle
Cassette
SRAM SX, 12V, 11-50
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Rodi TRYP30 - 29"
Tires
Pirelli SCORPION ProWall TRAIL -R- 29"x 2.4
Brakes
Brakes
SRAM GUIDE T 4 Piston disc brake
Cockpit
Stem
FSA Logo-60mm- Ø31,8 - Rise +6°
Handlebar
FSA 760mm- Ø31,8 - Rise 15mm - Sweep 6°
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
SWITCH SW Ø 30.9, S - 80mm / M - 100mm / L - 125mm
Motor & Battery
Motor
Yamaha PW X3, Torque/Coppia: 85 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 358 mm | 358 mm | 358 mm |
| Front Center | 721 mm | 752 mm | 772 mm |
| Reach | 407 mm | 433 mm | 453 mm |
| Top Tube Length | 573 mm | 602 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66.5 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1193 mm | 1224 mm | 1244 mm |
| Bottom Bracket Drop | 16 mm | 16 mm | 16 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
