Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Fork Suntour Zeron
-
Groupset SX Eagle -
Suspension Full -
Motor Yamaha 75Nm mid-drive -
Battery Fantic, Lithium Ion, 36 Volt, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Sizes: S - M - L
Suspension Fork
Suntour Zeron 35 150mm
Rear Shock
Suntour Edge-R Plus
Drivetrain
Rear Derailleur
SRAM SX
Shift Levers
SRAM SX Eagle
Cassette
SRAM SX, 12V, 11-50
Crank
SRAM 34t
Chain
SRAM SX
Wheels
Rims
Rodi TRYP30 - 29"
Tires
Pirelli SCORPION ProWall Trail -R- 29"x 2.4
Brakes
Brakes
SRAM LEVEL 2 Piston disc brake
Cockpit
Stem
Promax-60mm-Rise+6°-ø31,8
Handlebar
Promax-760mm-Rise 18mm-ø31,8
Seat
Saddle
Selle Italia MODEL-X Comfort Superflow 145
Seatpost
Telescopico Promax Ø30.9
Motor & Battery
Motor
Yamaha PW S2, Torque/Coppia: 75 Nm
Battery
Fantic, Lithium Ion, 36 Volt, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 358 mm | 358 mm | 358 mm |
| Front Center | 721 mm | 752 mm | 772 mm |
| Reach | 407 mm | 433 mm | 453 mm |
| Top Tube Length | 573 mm | 602 mm | 627 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 390 mm | 430 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1193 mm | 1224 mm | 1244 mm |
| Bottom Bracket Drop | 16 mm | 16 mm | 16 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
