Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Advanced MMC Carbon Fiber frame w/ 3KP weave, InsideOut internal molding process, machined threaded aluminum BB shell, Carbon Fiber dropouts & 6061 forged aluminum replaceable derailleur hanger
Suspension Fork
Felt Aero Road UHC Advanced monocoque fork; 100% Carbon Fiber 1.125" steerer tube, crown, blades, & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2 braze-on
Shift Levers
Shimano Ultegra Di2 STI
Cassette
Shimano, 11-25T
Crank
Shimano Ultegra Hollowtech-II, 53/39T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano 10-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Fulcrum Racing Quattro
Rear Hub
Fulcrum Racing Quattro
Rims
Fulcrum Racing Quattro
Spokes
Fulcrum Racing Quattro bladed aero stainless steel
Tires
Vittoria Rubino Pro Slick, 700c x 23c, 150 tpi
Brakes
Brakes
Shimano Ultegra Super SLR dual pivot w/ cartridge brake pads
Brake Levers
Shimano Ultegra Di2 STI
Cockpit
Stem
3T ARX Team 7075 T6 aluminum w/titanium bolts, +/-6° rise, Ø31.8mm bar clamp, 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm.
Handlebar
3T Ergonova Team HM Carbon Fiber, ergonomic, compatible with most clip-ons, Ø31.8mm, Drop=123mm, Reach=77 mm, 51cm=400mm, 54cm=420mm, 56cm=420mm, 58cm=440mm, 61cm=440mm
Grips
Devox Gel Velvet Tape w/ Devox 3D logos
Headset
FSA 1.125" Integrated w/ 25mm aluminum cone spacer, 2 x 10mm PC headset spacer, Felt compression device, Carbon Fiber top cap & 7075 anodized aluminum bolt
Seat
Saddle
Prologo Zero T1.4, Carbon Fiber injected base w/light foam padding & Tttanium rails
Seatpost
Felt Aero UHC Advanced Carbon Fiber Standard Offset Bladed Monocoque Design
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.41 mm | 1.46 mm | 1.47 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 578 mm | 581 mm | 584 mm | 598 mm | 620 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 56 mm | 55 mm | 56 mm | 52 mm |
| Stack | 511 mm | 532 mm | 553 mm | 572 mm | 593 mm |
| Reach | 376 mm | 377 mm | 380 mm | 389 mm | 410 mm |
| Top Tube Length | 521 mm | 536 mm | 551 mm | 566 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.125 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 403 mm | 403 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 974 mm | 980 mm | 993 mm | 1016 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 740 mm | 765 mm | 785 mm | 789 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR2 completes the Felt Ar2 model. 9 bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6199$. Doing a quick comparison, we notice that AR2 price is 47.21% more expensive than the average cost of an Aero bike.
Average weight for Aero bikes
Aero bikes weigh an average of 7.34 kg (16.18 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 7.26 kg (16.01 lbs), Felt bike is slightly lighter than average. In conclusion, the average Aero bike weighs 1.1% more than AR2.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The AR2 2013 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AR2 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
