Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Advanced carbon fiber, MMC w/ InsideOut construction, BB30, carbon fiber dropouts, 7075 CNC aluminum replaceable rear derailleur hanger, electronic-specific internal cable routing
Suspension Fork
Felt Aero Road UHC Ultimate carbon fiber monocoque construction, AeroTaper 1.125" - 1.25" carbon fiber steerer tube w/ integrated crown race, crown, blades & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra 11-speed Di2 short cage
Front Derailleur
Shimano Ultegra 11-speed Di2 braze-on
Shift Levers
Shimano Ultegra 11-speed Di2 w/ secondary sprint shifters
Cassette
Shimano Ultegra 11-speed, 11-25T
Crank
Shimano Ultegra 11-speed 48cm = 165mm 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm
Bottom Bracket
FSA BB30 w/ 24mm spindle reducers
Chain
Shimano Ultegra 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
3T Accelero 40 Team Stealth
Rear Hub
3T Accelero 40 Team Stealth, 11-speed
Rims
3T Accelero 40 Team Stealth carbon fiber
Spokes
3T Accelero 40 Team Stealth
Tires
Vittoria Diamante Pro Light, 220tpi, 700 x 23c
Brakes
Brakes
Shimano Ultegra F: dual pivot caliper, R: direct mount
Brake Levers
Shimano Ultegra 11-speed Di2
Cockpit
Stem
3T ARX II Team Stealth w/ titanium bolts, +/-6° rise, Ø31.8mm 48cm = 80mm 51cm = 90mm 54 - 56cm = 100mm 58cm = 110mm 61cm = 120mm
Handlebar
3T Tornova Team Stealth carbon fiber, 83mm reach, 139mm drop, Ø31.8mm 48 - 51cm = 400mm 54 - 56cm = 420mm 58 - 61cm = 440mm
Grips
Felt VelvetGel Tape
Headset
FSA No. 38 integrated, 1.125" - 1.25" sealed cartridge bearing w/ aluminum 4.5mm cone spacer, 20mm optional secondary cone spacer, 2 x 10mm + 1 x 5mm PC headset spacers, Felt compression device, carbon fiber top cap & aluminum bolt
Seat
Saddle
Prologo Zero II TiRox
Seatpost
Felt Vibration Reducing Aero Road flip position UHC carbon fiber w/ 3T DiffLock™ Comfort Module internals, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.37 mm | 1.42 mm | 1.44 mm | 1.44 mm | 1.47 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 580 mm | 588 mm | 603 mm | 622 mm |
| Rake | 52 mm | 50 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61 mm | 52 mm | 56 mm | 55 mm | 52 mm | 51 mm |
| Stack | 516 mm | 529 mm | 552 mm | 573 mm | 594 mm | 623 mm |
| Reach | 373 mm | 385 mm | 389 mm | 398 mm | 412 mm | 423 mm |
| Top Tube Length | 516 mm | 536 mm | 551 mm | 566 mm | 586 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 550 mm | 590 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm | 210 mm |
| Chainstay Length | 414 mm | 414 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 980 mm | 983 mm | 986 mm | 994 mm | 1009 mm | 1030 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
AR2 completes the Felt Ar2 model. Felt launched 9 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6199$. If we compare this with the average Aero bike cost we notice that the price is 47.21% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
AR2 components
Fork material
AR2 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The AR2 2014 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AR2 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
