Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Advanced MMC carbon fiber w/ 3KP weave, InsideOut internal molding process, machined threaded aluminum BB shell, internal Di2 or mechanical cable routing, carbon fiber dropouts & 7075 CNC machined aluminum replaceable derailleur hanger
Suspension Fork
Felt Aero Road UHC Performance monocoque fork, 100% carbon fiber 1.125"" steerer tube, crown, blades, & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2 braze-on
Shift Levers
Shimano Ultegra Di2 STI
Cassette
Shimano 11-25T
Crank
Shimano Ultegra, 53/39T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano 10 speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
MAVIC QRM aero aluminum 20H w/ BR101 quick release
Rear Hub
MAVIC QRM Aero aluminum 20H w/ FTS-L Shimano 10 speed compatible freehub body & BR101 quick release
Rims
MAVIC Cosmic Elite 30mm deep 6106 aluminum rim, SUP welded, UB control braking surface, 20H front, 20H rear
Spokes
MAVIC Cosmic Elite stainless steel bladed, butted, straight pull, laced radial front, 2x drive, radial non-drive rear; brass external nipples
Tires
Vittoria Rubino Pro Slick, 700c x 23c
Brakes
Brakes
Shimano Ultegra Super SLR dual pivot w/ cartridge brake pads
Brake Levers
Shimano Ultegra Di2 STI
Cockpit
Stem
Felt SL 6061 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, custom Cr-Mo bolts, 131g; 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm
Handlebar
Felt VS Aero 2014 triple butted aluminum w/ aerodynamic wing top section, w/ Variable Shape ergonomic drop, Ø31.8mm, 51cm=400mm, 54cm-56cm=420mm, 58cm-61cm=440mm
Grips
Felt gel tape w/ Felt logos
Headset
FSA 1.125"" integrated, w/ aluminum 25mm conical spacer, 2 X 10mm aluminum headset spacers, Felt aluminum top cap & 7075 anodized aluminum bolt
Seat
Saddle
Felt SL road saddle w/ carbon fiber injection molded base, polyurethane foam, embossed cover & hollow Cr-Mo rails
Seatpost
Felt Aero UHC Advanced carbon fiber standard offset bladed monocoque design, length = 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.41 mm | 1.45 mm | 1.47 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 578 mm | 581 mm | 584.32 mm | 598 mm | 620 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 56 mm | 55 mm | 56 mm | 52 mm |
| Stack | 510 mm | 531 mm | 553 mm | 572 mm | 593 mm |
| Reach | 376 mm | 377 mm | 381 mm | 389 mm | 410 mm |
| Top Tube Length | 521 mm | 536 mm | 551.12 mm | 566 mm | 594 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.125 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 403 mm | 403 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 974 mm | 980 mm | 993 mm | 1016 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 740 mm | 765 mm | 785 mm | 789 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
AR3 completes the Felt Ar3 model. Felt launched 9 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
If you want an acceptable Aero bike you should know that the average price is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Felt released this model in 2012, its price was 4999$. Comparing the average cost of an Aero bike to this one, you will see that AR3 price is 18.71% higher.
Aero bikes average weight
The average weight for Aero bikes is 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 7.89 kg (17.39 lbs), the AR3 model is a bit heavier than average. In short, the average Aero bike weight is 7.49% lower than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on AR3 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Felt AR3 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
