Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Performance carbon fiber, MMC with InsideOut construction, BSA threaded bottom bracket shell, carbon fiber dropouts, replaceable rear derailleur hanger, internal mechanical or internal electronic cable routing
Suspension Fork
Felt Aero Road UHC Advanced carbon fiber monocoque construction, AeroTaper 1.125" - 1.25" carbon fiber steerer tube, integrated crown race, crown, blades and dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra R8000 11-speed short cage
Front Derailleur
Shimano Ultegra R8000 braze-on
Shift Levers
Shimano Ultegra R8000 11-speed
Cassette
Shimano 11-speed, 11-28T
Crank
Shimano Ultegra R8000, 52/36T, 48cm: 165mm -- 51cm: 170mm --- 54 - 56cm: 172.5mm --- 58 - 61cm: 175mm
Bottom Bracket
Shimano Hollowtech BSA threaded
Chain
Shimano 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Devox ARH1, sealed cartridge bearing, 100mm QR, 20H
Rear Hub
Devox ARH1, sealed cartridge bearing, 11-speed, 130mm QR, 24H
Rims
Devox 55 carbon, tubeless ready, 17mm inner width, 55mm depth
Spokes
2.0mm stainless steel with aluminum nipples
Tires
Continental Grand Prix 4000 S II folding, 700 x 23c
Brakes
Brake Levers
Shimano Ultegra R8000
Cockpit
Stem
Easton EC70 ±6° rise, Ø31.8mm, 48cm: 80mm --- 51cm: 90mm --- 54 - 56cm: 100mm --- 58cm: 110mm --- 61cm: 120mm
Handlebar
Easton EC70 Aero, 80mm reach, 125mm drop, Ø31.8mm, 48 - 54cm: 400mm --- 56 - 61cm: 420mm
Grips
Felt VelvetGel tape with 3M reflective base with reflective Felt Bubble-Tech F-Wing bar end plugs
Headset
FSA integrated sealed cartridge bearing with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), No. 382/DJ, 1.125" - 1.25"
Seat
Saddle
Fizik Arione R5
Seatpost
Felt Vibration Reducing Aero Road flip position UHC Advanced carbon fiber with 3T DiffLock Comfort Module internals, 48 - 51cm: 280mm length, 5mm offset --- 54 - 61cm: 350mm length, 25mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.37 mm | 1.42 mm | 1.44 mm | 1.44 mm | 1.47 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 580 mm | 588 mm | 603 mm | 622 mm |
| Rake | 52 mm | 50 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61 mm | 52 mm | 56 mm | 944 mm | 52 mm | 51 mm |
| Stack | 516 mm | 529 mm | 552 mm | 573 mm | 594 mm | 623 mm |
| Reach | 373 mm | 385 mm | 389 mm | 398 mm | 412 mm | 423 mm |
| Top Tube Length | 516 mm | 536 mm | 551 mm | 566 mm | 586 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 550 mm | 590 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm | 210 mm |
| Chainstay Length | 414 mm | 414 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 980 mm | 983 mm | 986 mm | 994 mm | 1009 mm | 1030 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 716 mm | 746 mm | 770 mm | 791 mm | 818 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR3 is part of the Felt Ar3 model. Felt launched 9 bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Aero bikes average price
Our math shows that the average cost of a dependable Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Felt released this model in 2018, its price was 3999$. If we compare this with the average Aero bike cost we notice that the price is 5.3% lower.
Average weight for Aero bikes
The average weight for Aero bikes is 7.34 kg (16.18 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 7.7 kg (16.98 lbs), Felt bike is slightly heavier than average. To sum up, it’s 4.9% heavier than the average weight of Aero bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the AR3 bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt AR3 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
