Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHM High Modulus Modular Monocoque carbon fiber frame with 3KP Finish; internal cable routing, carbon fiber dropouts & replaceable derailleur hanger
Suspension Fork
Felt 1.3A Bladed Aero UHM High Modulus Fork with aero carbon fiber blades, carbon fiber crown, carbon fiber steerer tube & carbon fiber Dropouts; 450 grams
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra SS Short Cage
Front Derailleur
Shimano Ultegra braze-on, double
Shift Levers
Shimano Ultegra STI, 20 speed
Cassette
Shimano 10-Speed Cassette, 11-25T
Crank
Shimano Ultegra, 53/39T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano Ultegra 6700 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt AeroR1 Sealed Bearing CNC Machined 7075 Aluminum 20H w/ Cr-Mo Quick Release Skewer
Rear Hub
Felt AeroR1 Sealed Bearing CNC Machined 7075 Aluminum 24H w/ Cr-Mo Quick Release Skewer
Rims
Felt AeroR2 700c 28mm Deep Aluminum w/ CNC Machined Braking Surface, 20H Front/24H Rear
Spokes
DT Aero Bladed w/ Aluminum Nipples
Tires
Vittoria Rubino Pro Slick Folding, 700c x 23c, 150tpi
Brakes
Brakes
Shimano Ultegra Super SLR Dual Pivot w/ Cartridge Brake Shoes
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
Felt 1.1 2014 Aluminum 3D Forged Ø31.8mm w/ +/-8° Rise, 51cm=80mm, 54cm=90mm, 56cm=100mm, 58cm=110mm, 61cm=110mm
Handlebar
Felt 1.3 2014 Triple Butted Aluminum w/ Aerodynamic Wing Top Section, w/ Ergonomic Drop, Ø31.8mm, 51cm=400mm, 54cm-56cm=420mm, 58cm-61cm=440mm
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo
Headset
FSA 1 1/8 Integrated w/ 20mm Cone & 2 X 7.5mm Spacer Stack
Seat
Saddle
Felt 1.2 Road Saddle w/ Carbon Injected Base, Embossed Cover & Hollow Cr-Mo Rails
Seatpost
Felt 1.1a UHM Carbon Fiber Standard Offset Bladed Monocoque Design x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 578 mm | 581 mm | 584 mm | 589 mm | 620 mm |
| Rake | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.125 ° | 73 ° | 73 ° |
| Seat Tube Length | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72.5 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 121.6 mm | 141.6 mm | 161.6 mm | 181.6 mm | 201.6 mm |
| Chainstay Length | 403 mm | 403 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 971 mm | 974 mm | 980 mm | 993 mm | 1016 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 740 mm | 765 mm | 785 mm | 789 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR4 is a Felt Ar4 model. There are 7 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2010 for 3499$. Comparing this to the average Aero bike price, we see that the price is 20.35% lower.
Average weight for Aero bikes
Aero bikes weigh an average of 7.34 kg (16.18 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 7.68 kg (16.93 lbs), Felt bike is slightly heavier than average. In short, the average Aero bike weight is 4.63% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
AR4 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the AR4 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The AR4 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
