Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Performance carbon fiber, MMC with InsideOut construction, BSA threaded bottom bracket shell, carbon fiber dropouts, replaceable rear derailleur hanger, internal mechanical or internal electronic cable routing
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 11-speed short cage
Front Derailleur
Shimano 105 braze-on
Shift Levers
Shimano 105 11-speed
Cassette
Shimano 11-speed, 11-28T
Crank
Shimano 105, 52/36T, 48cm: 165mm -- 51cm: 170mm --- 54 - 56cm: 172.5mm --- 58 - 61cm: 175mm
Bottom Bracket
Shimano Hollowtech BSA threaded
Chain
Shimano 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Devox ARH2, sealed cartridge bearing, 100mm QR, 24H
Rear Hub
Devox ARH2, sealed cartridge bearing, 11-speed, 130mm QR, 28H
Rims
Devox 30; front: 17mm inner width, 27mm depth, --- rear: 17mm inner width, 30mm depth
Spokes
2.0 / 1.5 x 2.3mm butted aero stainless steel with aluminum nipples
Tires
Grand Sport Race folding, 700 x 23c
Brakes
Brake Levers
Shimano 105
Cockpit
Stem
Devox, ±7° rise, Ø31.8mm, 48cm: 80mm --- 51cm: 90mm --- 54 - 56cm: 100mm --- 58cm: 110mm --- 61cm: 120mm
Handlebar
Devox Aero Road VariableShape, 80mm reach, 130mm drop, Ø31.8mm, 48 - 54cm: 400mm --- 56 - 61cm: 420mm
Grips
Felt VelvetGel tape with 3M reflective base with reflective Felt Bubble-Tech F-Wing bar end plugs
Headset
FSA integrated sealed cartridge bearing with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), No. 382/DJ, 1.125" - 1.25"
Seat
Saddle
Fizik Arione R7
Seatpost
Felt Vibration Reducing Aero Road flip position UHC Advanced carbon fiber with 3T DiffLock Comfort Module internals, 48 - 51cm: 280mm length, 5mm offset --- 54 - 61cm: 350mm length, 25mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.37 mm | 1.42 mm | 1.44 mm | 1.44 mm | 1.47 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 579 mm | 580 mm | 588 mm | 603 mm | 622 mm |
| Rake | 52 mm | 50 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61 mm | 52 mm | 56 mm | 55 mm | 52 mm | 51 mm |
| Stack | 516 mm | 529 mm | 552 mm | 573 mm | 594 mm | 623 mm |
| Reach | 373 mm | 385 mm | 389 mm | 398 mm | 412 mm | 423 mm |
| Top Tube Length | 516 mm | 536 mm | 551 mm | 566 mm | 586 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 550 mm | 590 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm | 210 mm |
| Chainstay Length | 414 mm | 414 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 980 mm | 983 mm | 986 mm | 994 mm | 1009 mm | 1030 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 716 mm | 746 mm | 770 mm | 791 mm | 818 mm | 851 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR5 is part of the Felt Ar5 model. Felt released 9 bikes variations of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Felt AR5 price was 2499$. Doing a quick comparison, we notice that AR5 price is 68.51% lower than the average cost of an Aero bike.
Aero bikes average weight
Aero bikes have an average weight of 7.34 kg (16.18 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Felt AR5 it’s weighing 8.1 kg (17.86 lbs). At this weight, is considerably heavier than average. In short, the average Aero bike weight is 10.35% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
AR5 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the AR5 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AR5 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
