Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Road UHC Performance carbon fiber, MMC with InsideOut construction, BSA threaded bottom bracket shell, carbon fiber dropouts, replaceable rear derailleur hanger, internal mechanical or internal electronic cable routing Shock:
Suspension Fork
Felt Aero Road UHC Advanced carbon fiber monocoque construction, AeroTaper 1.125" - 1.25" carbon fiber steerer tube with integrated crown race, crown, blades and dropouts
Drivetrain
Rear Derailleur
Shimano 105 R7000 11-speed short cage
Front Derailleur
Shimano 105 R7000 braze-on
Shift Levers
Shimano 105 R7000 11-speed
Cassette
Shimano 11-speed, 11-28T
Crank
Shimano 105 R7000, 52/36T, 48cm: 165mm, 51cm: 170mm, 54 - 56cm: 172.5mm, 58 - 61cm: 175mm
Bottom Bracket
Shimano Hollowtech BSA threaded
Chain
Shimano 11-speed
Wheels
Front Hub
Devox ARH2, sealed cartridge bearing, 100mm QR, 24H
Rear Hub
Devox ARH2, sealed cartridge bearing, 11-speed, 130mm QR, 28H
Rims
Devox 30; front: 17mm inner width, 27mm depth, rear: 17mm inner width, 30mm depth
Spokes
2.0 / 1.5 x 2.3mm butted aero stainless steel with aluminum nipples
Tires
Grand Sport Race folding, 700 x 25c
Brakes
Brakes
Shimano 105 R7000 dual pivot caliper
Brake Levers
Shimano 105 R7000
Cockpit
Stem
Devox, ±7° rise, Ø31.8mm, 48cm: 80mm, 51cm: 90mm, 54 - 56cm: 100mm, 58cm: 110mm, 61cm: 120mm
Handlebar
Devox Aero Road VariableShape, 80mm reach, 130mm drop, Ø31.8mm, 48 - 54cm: 400mm, 56 - 61cm: 420mm
Headset
FSA integrated sealed cartridge bearing with Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), No. 382/DJ, 1.125" - 1.25"
Seat
Saddle
Fizik Arione R7
Seatpost
Felt Vibration Reducing Aero Road flip position UHC Advanced carbon fiber with 3T DiffLock Comfort Module internals, 48 - 51cm: 280mm length, 5mm offset, Felt VariMount Aero Road flip position UHC Advanced carbon fiber, 54 - 61cm: 350mm length, 25mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
AR5 completes the Felt Ar5 model. There are 9 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
Our math shows that the average cost of a dependable Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 2649$. If we compare this with the average Aero bike cost we notice that the price is 58.97% smaller.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on AR5 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt AR5 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
