Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2, Vision -
Suspension Rigid -
Drivetrain 2 × 10 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero TT/Tri UHC Performance MMC Carbon Fiber Frame w/ 3KP Finish. Full Aero Tubeset w/ Front & Rear wheel recesses, Di2 Optimized Internal Cable Routing, Forged horizontal dropouts
Suspension Fork
Felt Aero UHC Performance TT/Tri Carbon Fiber Fork w/ 3KP Weave; 7005 Aluminum 1 Steerer tube, Carbon Fiber Crown, Blades, and Dropouts, 434g
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 SS short cage
Front Derailleur
Shimano Dura-Ace Di2 braze on
Shift Levers
Shimano Dura-Ace Di2 SW-7971 & ST7971 dual shift point STI
Cassette
Shimano Cassette, 12-25T (650C Models: 11-23T)
Crank
Vision TriMax Aluminum 2 piece w/ Integrated MegaExo BB, A6061-T6 cold Forged solid Crank Arms, w/ AL7075 T6 Aluminum N10 5mm CNC TT Chainrings, Black AL7075 T6 Aluminum Torx T-30 Chainring Bolts, 110mm BCD, 909 grams (excluding BB) 52/38T; 48cm-50cm=170mm, 52cm-54cm=172.5mm, 56cm-60cm=175mm
Bottom Bracket
FSA Mega EXO
Chain
Shimano 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TTR-3 Sealed Bearing CNC Machined 7075 Aluminum 20H w/ Cr-Mo Quick Release Skewer
Rear Hub
Felt TTR-3 Sealed Bearing CNC Machined 7075 Aluminum 24H w/ Cr-Mo Quick Release Skewer
Rims
Felt TTR-3 700c 40mm Deep Section Aluminum w/ CNC Machined Braking Surface, 20H Front/24H Rear (650c Models: Felt TTR-3 650c)
Spokes
Alpina Bladed butted 1.8/0.9 x 2.3/1.8mm w/ Aluminum Nipples
Tires
Vittoria Zaffiro Pro, 700c x 23c, 60tpi (650C Models: Vittoria Rubino Pro, 650c x 23c, 150tpi)
Brakes
Brakes
Felt TTR Aero U-Brake Front, TRP Custom SuperLight U-Brake w/ Stainless Hardware & Teflon Bushings Rear w/ Cartridge Brake Shoes
Brake Levers
Shimano Dura-Ace Di2 ST7971 STI
Cockpit
Stem
Felt SL 6061 Aluminum 3D Forged +/-7° Rise, Ø26.0mm Bar Clamp, custom Cr-Mo bolts, 121g, 48cm=60mm, 50cm=80mm, 52cm=80mm, 54cm=90mm, 56cm=90mm, 58cm=100mm, 60cm=110mm.
Handlebar
Felt 3:1 Bayonet 7005 Superlight 390mm (48-52cm) or 420mm (54-60cm) Base Bar w/ Di2 Optimized Internal Cable Routing, Integrated Adjustable Length 7075 Aluminum ƒ Bend extensions & 6061 Aluminum arm rests w/ Gel Arm Rest Pads
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo on basebar w/ DEVOX Gel Velvet Tape w/ DEVOX 3D Logo wrapped extensions
Headset
FSA 1 Integrated w/ 20mm Cone & 3 X 5mm Spacer, Felt Tornado Aluminum Top Cap & 2024 Anodized Aluminum Bolt
Seat
Saddle
Felt SL Tri/TT Saddle w/ Carbon Injected base, Gel Nose, Custom Waterproof Cover w/ Extended Length Cr-Mo rails
Seatpost
Felt Aero UHC Advanced Carbon Fiber Bladed Monocoque Design x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.235 mm | 1.236 mm | 1.239 mm | 1.237 mm | 1.216 mm | 1.217 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 562 mm | 567.6 mm | 588.6 mm | 595.5 mm | 611.6 mm | 640.3 mm | 656.6 mm |
| Rake | 35 mm | 35 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 467 mm | 483 mm | 502 mm | 513 mm | 527 mm | 546 mm | 561 mm |
| Reach | 386 mm | 391 mm | 406 mm | 414 mm | 426 mm | 449 mm | 461 mm |
| Head Tube Length | 115 mm | 130 mm | 100 mm | 110 mm | 125 mm | 145 mm | 160 mm |
| Chainstay Length | 385 mm | 385 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 947 mm | 951 mm | 984 mm | 990 mm | 1007 mm | 1036 mm | 1052 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 703 mm | 720 mm | 743 mm | 764 mm | 779 mm | 780 mm | 780 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
B10 is a Felt B10 model. 1 bike variation carries this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Triathlon bikes
If you want an acceptable Triathlon bike you should know that the average price is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2011 and its price was 5799$. Doing a quick comparison, we notice that B10 price is 38.83% more expensive than the average cost of a Triathlon bike.
Triathlon bikes average weight
Triathlon bikes have an average weight of 8.9 kg (19.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 8.51 kg (18.76 lbs), Felt bike is slightly lighter than average. In conclusion, the average Triathlon bike weighs 4.58% more than B10.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
B10 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on B10 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
