Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, microSHIFT -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt TT/Tri UHC Performance MMC carbon fiber w/ 3KP weave, mechanical internal cable routing, aluminum dropout & derailleur hanger
Suspension Fork
Felt Aero TT/Tri UHC Performance carbon fiber crown, blades, & dropouts w/ 1"" aluminum steerer tube
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra SS short cage
Front Derailleur
Shimano Ultegra braze-on
Shift Levers
Micro.shift Shimano compatible bar end
Cassette
10 speed 11-25T
Crank
FSA Omega Compact MegaExo, 50/34T; 52cm=170mm, 54cm=172.5mm
Bottom Bracket
FSA MegaExo
Chain
SunRace 10 speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TTR4 premium sealed bearing forged aluminum w/ Felt quick release, 24H
Rear Hub
Felt TTR4 premium sealed bearing forged Shimano 9/10 speed compatible freehub w/ Felt quick release, 28H
Rims
Felt TTR4 aluminum clincher 30mm deep 24H front, 28H rear
Spokes
Swiss 2.0mm stainless steel laced radial front, 3x rear w/ brass nipples
Tires
Vittoria Zaffiro Slick foldable, 700c x 23c
Brakes
Brakes
Dual pivot w/ stainless hardware & cartridge brake pads
Brake Levers
TRP aero aluminum
Cockpit
Stem
Felt FitWoman SL 6061 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, custom Cr-Mo bolts, 131g; 52cm=60mm, 54cm=70mm
Handlebar
Felt Aero TT/Tri 6061 butted base bar, Ø31.8mm 52cm=390mm, 54cm=390mm w/ clip-on adjustable length 7075 aluminum ƒ bend extensions & aluminum arm rests w/ gel arm rest pads
Grips
Devox Tri-tip ergonomic base bar grip w/ Felt Gel Velvet tape wrapped extensions
Headset
FSA 1"" integrated w/ 7.2mm + 20mm cone & 3 X 5mm spacers, Felt Tornado top cap & 2024 anodized aluminum bolt
Seat
Saddle
Prologo Nago EVO Tri40 DEA w/ nylon injected base, active density padding, custom cover w/ extended length rails
Seatpost
Felt Aero UHC Advanced carbon fiber standard offset bladed monocoque design, length = 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | SM | MD | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.24 mm | 1.24 mm | 1.24 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 266 mm | 266 mm |
| Front Center | 562 mm | 567.6 mm | 588.6 mm | 595.5 mm |
| Rake | 35 mm | 35 mm | 40 mm | 40 mm |
| Trail | 68 mm | 65 mm | 63 mm | 61 mm |
| Stack | 462 mm | 478 mm | 497 mm | 508 mm |
| Reach | 381 mm | 386 mm | 401 mm | 409 mm |
| Top Tube Length | 485 mm | 495 mm | 515 mm | 539.9 mm |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 100 mm | 110 mm |
| Chainstay Length | 380 mm | 380 mm | 400 mm | 400 mm |
| Wheelbase | 942 mm | 946 mm | 979 mm | 985 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 70 mm | 70 mm |
| Standover Height | 698 mm | 715 mm | 738 mm | 759 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
B16W is part of the Felt B16w model. Felt launched 1 bike of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Triathlon bikes
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Felt released this model in 2012, its price was 2199$. Comparing the average cost of a Triathlon bike to this one, you will see that B16W price is 89.95% smaller.
Average weight for Triathlon bikes
If we make a quick analysis of the average weight of a Triathlon bike, we get 8.9 kg (19.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly heavier than average, B16W has a weight of 9.24 kg (20.37 lbs). To sum up, it’s 3.82% heavier than the average weight of Triathlon bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
B16W components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on B16W are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
