Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, Force -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
152cm - 169cm
51cm
166cm - 174cm
54cm
171cm - 179cm
56cm
176cm - 184cm
58cm
181cm - 189cm
61cm
186cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt BREED, SuperLite aluminum
Suspension Fork
Felt Gravel, UHC Performance carbon with aluminum steerer tube
Drivetrain
Rear Derailleur
47 cm: SRAM Force 1, 22-S, 51, 54, 56, 58, 61 cm: SRAM Force 1
Front Derailleur
Shimano GRX, FD-RX812
Shift Levers
SRAM Force 1
Cassette
SRAM PG-1130, 11-42 T
Crank
Praxis Works Zayante Carbon-S, 40 T
Chain
SRAM PC-1130
Wheels
Rims
47 cm: Devox WheelRDS.A0, Tubeless ready, Center lock, 12x100/12x142 mm, 51, 54, 56, 58, 61 cm: Devox WheelRDS.A0
Tires
Vittoria Terreno Dry
Brakes
Brakes
Front: Shimano BR-RX400, 2-piston, Hydraulic disc brake, Rear: Shimano BR-RX400, 2-piston, Hydraulic disc brake
Cockpit
Stem
Devox StemR.A2
Handlebar
47 cm: Devox DBar.A1 GXA 31.8 mm, 400 mm, 51, 54, 56, 58, 61 cm: Devox DBar.A1 GXA 31.8 mm
Headset
IS (NO.42)
Seat
Saddle
Prologo Dimension NDR T4.0
Seatpost
47 cm: Devox Post.C2, 300 mm, 51, 54, 56, 58, 61 cm: Devox Post.C2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.455 mm | 1.479 mm | 1.494 mm | 1.519 mm | 1.545 mm | 1.577 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 604 mm | 609 mm | 620 mm | 625 mm | 629 mm | 638 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 72 mm | 71 mm | 66 mm | 64 mm | 65 mm |
| Stack | 544 mm | 562 mm | 575 mm | 591 mm | 607 mm | 626 mm |
| Reach | 374 mm | 380 mm | 385 mm | 389 mm | 393 mm | 397 mm |
| Top Tube Length | 530 mm | 540 mm | 555 mm | 570 mm | 585 mm | 600 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 100 mm | 116 mm | 130 mm | 145 mm | 160 mm | 180 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1013 mm | 1019 mm | 1030 mm | 1035 mm | 1039 mm | 1048 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 687 mm | 708 mm | 737 mm | 757 mm | 777 mm | 805 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 171 cm | 176 cm | 181 cm | 186 cm |
| Rider Max Height | 169 cm | 174 cm | 179 cm | 184 cm | 189 cm | 195 cm |
