Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset RED, Force -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Cyclocross UHC Performance MMC carbon fiber w/ 3KP weave, shoulder friendly top tube, InsideOut internal molding process, BB30 shell, Di2 internal/mechanical external convertible cable routing, 1 piece forged aluminum dropouts & 6061 forged aluminum replaceable derailleur hanger
Suspension Fork
Felt CXR UHC Advanced 3KP weave monocoque fork, carbon fiber Controltaper 1.125"" --> 1.5"" steerer tube, crown, & fork blades w/ cantilever brake pivots, & forged aluminum dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM Red
Front Derailleur
SRAM Force Ø31.8mm clamp
Shift Levers
SRAM Red Double Tap
Cassette
SRAM 11-26T
Crank
SRAM S300 BB30 3D cold forged aluminum cyclocross , 46/38T; 47cm=165mm, 50cm=170mm, 53cm=172.5mm, 55cm-60cm=175mm
Bottom Bracket
SRAM BB30
Chain
SRAM 10 speed w/ PowerLock
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Fulcrum Racing 5 CX aluminum 20H & Fulcrum quick release
Rear Hub
Fulcrum Racing 5 CX aluminum 24H 2:1 w/ Shimano 10 speed compatible freehub body & Fulcrum quick release
Rims
Fulcrum Racing 5 CX 24mm deep 6061 aluminum rim, 20H front, 24H rear
Spokes
Fulcrum Racing 5 CX straight pull aero Dynamic Balance stainless steel laced radial front, 2:1 Two-to-One™ 2x drive, radial non-drive rear; brass external nipples
Tires
Vittoria Cross XG 700c x 32c Kevlar foldable
Brakes
Brakes
TRP Euro X cyclocross cantilevers w/ road cartridge brake pads. & straddle cable barrel adjuster
Brake Levers
SRAM Red
Cockpit
Stem
Felt SL 6061 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, custom Cr-Mo bolts, 131g; 47cm=80mm, 50cm=90mm, 53cm-55cm=100mm, 57cm=110mm, 60cm=120mm
Handlebar
Felt VS SL 6061 butted aluminum w/ Felt Variable Shape ergonomic drop, Ø31.8mm, 47cm=380mm, 50cm=400mm, 53cm=420mm, 56cm-60cm=440mm
Grips
Felt All Weather tape w/ no-slip texture
Headset
FSA NO.42 CX 1.125"" --> 1.5"" integrated, w/ aluminum 15mm conical spacer w/ brake cable hanger, 2 X 10mm aluminum headset spacer, 1 x 5mm aluminum headset spacer, Felt carbon fiber top cap & 7075 anodized aluminum bolt
Seat
Saddle
Felt SL road saddle w/ carbon fiber injection molded base, polyurethane foam, embossed cover & hollow Cr-Mo rails
Seatpost
Felt CXR.2 forged 6061 aluminum 1 piece lightweight twin side clamp bolt design, Ø27.2mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.45 mm | 1.45 mm | 1.47 mm | 1.46 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 583 mm | 584 mm | 585 mm | 605 mm | 620 mm | 646 mm |
| Rake | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 64 mm | 68 mm | 64 mm | 64 mm | 64 mm | 59 mm |
| Stack | 527 mm | 540 mm | 551 mm | 570 mm | 589 mm | 609 mm |
| Reach | 370 mm | 377 mm | 379 mm | 393 mm | 402 mm | 416 mm |
| Top Tube Length | 512 mm | 527 mm | 542 mm | 562 mm | 582 mm | 607 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 570 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm | 195 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1007 mm | 1007 mm | 1009 mm | 1029 mm | 1044 mm | 1070 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 728 mm | 753 mm | 781 mm | 798 mm | 816 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
F3X is part of the Felt F3x model. There are 6 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Cyclocross bikes
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3499$. Doing a quick comparison, we notice that F3X price is 73.91% more expensive than the average cost of a Cyclocross bike.
Average weight for Cyclocross bikes
On a deeper look, we notice that the average weight of a Cyclocross bike is 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly lighter than average, F3X has a weight of 8.69 kg (19.16 lbs). In other words, this model is 1.15% lighter than the average Cyclocross bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
F3X components
Fork material
F3X has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The F3X 2012 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt F3X is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
