Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Race Road UHC Performance carbon fiber, MMC w/ InsideOut construction, threaded BB, replaceable rear derailleur hanger
Suspension Fork
Felt Race Road UHC Performance carbon fiber monocoque construction, ControlTaper 1.125" - 1.5" carbon fiber steer tube, crown, blades & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 11-speed short cage
Front Derailleur
Shimano 105 11-speed braze-on
Shift Levers
Shimano 105 11-speed STI
Cassette
Shimano 105 11-speed, 11-28T
Crank
Shimano 105 11-speed 48cm = 165mm 51cm = 170mm 54 - 56cm = 172.5mm 58 - 61cm = 175mm
Bottom Bracket
Shimano Hollowtech II
Chain
Shimano 105 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt R3, sealed bearing, 28H
Rear Hub
Felt R3, sealed cartridge bearing, 32H, 11-speed
Rims
Felt Road RSL3 (tubeless ready), 22mm width, 24mm depth
Spokes
2.0 / 1.8mm butted stainless steel w/ aluminum nipples
Tires
Vittoria Rubino Pro Tech, 700 x 23c
Brakes
Brakes
Shimano dual pivot caliper
Brake Levers
Shimano 105 11-speed STI
Cockpit
Stem
Felt SuperLite, +/-7° rise, Ø31.8mm 48cm = 80mm 51cm = 90mm 54 - 56cm = 100mm 58cm = 110mm 61cm = 120mm
Handlebar
Felt SuperLite Road VariableShape, 71mm reach, 118mm drop, Ø31.8mm 48cm = 380mm 51cm = 400mm 54 - 56cm = 420mm 58 - 61cm = 440mm
Grips
Felt Gel Tape
Headset
FSA NO.38/42, 1.125" - 1.5" sealed cartridge bearing w/ Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1x 10mm + 2 x 5mm PC headset spacers, Felt compression device, carbon fiber top cap & aluminum bolt
Seat
Saddle
Prologo Nago Evo T2.0
Seatpost
Felt Race Road UHC Performance carbon fiber, Ø27.2mm, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.34 mm | 1.35 mm | 1.37 mm | 1.38 mm | 1.44 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 578 mm | 580 mm | 588 mm | 604 mm | 622 mm |
| Rake | 52 mm | 50 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 61 mm | 52 mm | 56 mm | 54 mm | 53 mm | 52 mm |
| Stack | 506 mm | 520 mm | 532 mm | 554 mm | 575 mm | 613 mm |
| Reach | 376 mm | 387 mm | 395 mm | 403 mm | 418 mm | 425 mm |
| Top Tube Length | 516 mm | 536 mm | 551 mm | 566 mm | 586 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 540 mm | 570 mm | 610 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 140 mm | 160 mm | 200 mm |
| Chainstay Length | 409 mm | 409 mm | 411 mm | 411 mm | 413 mm | 416 mm |
| Wheelbase | 975 mm | 977 mm | 980 mm | 989 mm | 1006 mm | 1028 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 687 mm | 723 mm | 756 mm | 776 mm | 802 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
F5 is part of the Felt F5 model. Felt launched 9 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Race bikes average price
According to our math, the average price for a trustworthy Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1999$. In conclusion, this bike price is 67.58% smaller than the price of the average Race bike.
F5 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the F5 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Felt F5 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
