Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset X1 -
Suspension Rigid -
Drivetrain Single Speed
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Track UHC Advanced + Nano carbon fiber, MMC with InsideOut construction, BSA threaded bottom bracket shell, horizontal dropouts with titanium surfaces, integrated chain tensioners
Suspension Fork
Felt Aero Track UHC Advanced carbon fiber monocoque construction, 1.125"" carbon fiber steerer tube, crown, blades and dropouts with aluminum steerer tube plug and integrated compression device
Rear Shock
n/a
Drivetrain
Rear Derailleur
n/a
Front Derailleur
n/a
Shift Levers
n/a
Cassette
15T x 1/8" with lockring
Crank
Rotor 3D24 TRACK, 49T x 1/8" chainring 144mm BCD, 52cm: 165mm --- 55cm: 167.5mm --- 57 - 60cm: 170mm
Bottom Bracket
Rotor BSA Track with 24mm bearings
Chain
KMC X101 1-speed 1/8"
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TkR1, sealed cartridge bearing, 100mm with track nuts, 24H
Rear Hub
Felt TkR1, sealed cartridge bearing, double-threaded fixed / fixed, 120mm with track nuts, 24H
Rims
Felt TkR1 tubular by Reynolds, 62mm depth
Spokes
Bladed double butted stainless steel with aluminum spoke nipples
Tires
Challenge Pista Ultra, l 1000+tpi Silk casing, 700x22c
Brakes
Brake Levers
n/a
Cockpit
Stem
3T Team Stem with titanium bolts, ±10° rise, Ø31.8mm, 51 - 54cm: 85mm --- 56 - 61cm: 100mm
Handlebar
3T SCATTO LTD carbon fiber, Ø31.8mm, 51-54cm: 350mm --- 56 - 61cm: 370mm
Grips
Felt VelvetGel tape with Felt Bubble-Tech F-Wing bar end plugs
Headset
FSA IS integrated, 1.125" sealed cartridge bearing with custom TK1 cone spacer, Felt top cap
Seat
Saddle
Prologo Zero II CPC TiRox
Seatpost
Felt Tk1 UHC Advanced carbon fiber with 3T DiffLock internals
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.19 mm | 1.16 mm | 1.17 mm | 1.19 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 566 mm | 582 mm | 598 mm | 619 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 60 mm | 59 mm | 54 mm | 52 mm |
| Stack | 472 mm | 483 mm | 504 mm | 530 mm |
| Reach | 398 mm | 415 mm | 429 mm | 447 mm |
| Top Tube Length | 533 mm | 553 mm | 573 mm | 603 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 505 mm | 525 mm | 545 mm | 570 mm |
| Head Tube Angle | 73 ° | 73.5 ° | 74 ° | 74.5 ° |
| Head Tube Length | 80 mm | 90 mm | 110 mm | 135 mm |
| Chainstay Length | 378 mm | 378 mm | 378 mm | 378 mm |
| Wheelbase | 938 mm | 953 mm | 970 mm | 990 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
TK1 completes the Felt Tk1 model. Felt launched 13 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Track bikes average price
According to our math, the average price for a trustworthy Track bike is 1503$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Track bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4999$. If we compare this with the average Track bike cost we notice that the price is 232.6% higher.
Track bikes average weight
If we make a quick analysis of the average weight of a Track bike, we get 7.85 kg (17.31 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 6.8 kg (14.99 lbs), Felt bike is much lighter than average. To sum up, it’s 15.44% lighter than the average weight of Track bikes.
TK1 components
Fork material
TK1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The TK1 2018 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
