Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset X1 -
Suspension Rigid -
Drivetrain Single Speed
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt TkR Track Specific Custom Butted Super-light 7005 smooth welded Aluminum tubes, Full Aero 70mm Deep ST w/ Rear wheel recess & Semi Aero DT, bladed monostay & aero seatstays w/ horizontal CNC dropouts w/ stainless steel inserts
Suspension Fork
Felt TkR Track Specific UHC Performance Carbon Fiber w/ 1.125 Aluminum Steerer & bladed aero carbon fiber fork blades, 30mm offset (52cm uses 43mm offset), drilled crown for Front brake
Rear Shock
n/a
Drivetrain
Rear Derailleur
n/a
Front Derailleur
n/a
Shift Levers
n/a
Cassette
Track 15T x 1/2 pitch x 1/8 width fixed sprocket w/ lock ring
Crank
SRAM TruVativ Omnium Track GXP, Cold Forged Aluminum, Polished & Mirror Black Anodized w/ CNC Aluminum Chainring 48T x 1/8; 52cm-54cm=165mm, 56cm=167.5mm, 58cm=170mm, 60cm=170mm
Bottom Bracket
SRAM GXP Team External Bearings
Chain
KMC Z510HX Track 1/8 width
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TkR-2 Low-Flange w/ Sealed Cartridge Bearing 28H
Rear Hub
Felt TkR-2 Double-Threaded Fixed/Fixed Low-Flange w/ Sealed Cartridge Bearings, 28H
Rims
Felt TkR-2 700c 40mm Deep Aluminum Aero Track, 28H Radially Laced Front/28H 3 cross Rear
Spokes
Bladed butted 2.0/0.9 x 2.3/1.8mm w/ Aluminum nipples
Tires
Vittoria Diamante Pro Pista, 700c x 23c
Brakes
Brakes
n/a
Brake Levers
n/a
Cockpit
Stem
Felt TkR 6061 Aluminum 3D Forged +/-7° Rise, Ø31.8mm Bar Clamp, custom Cr-Mo bolts, 128g, 52cm=90mm, 54cm=100mm, 56cm=110mm, 58cm=110mm, 60cm=120mm
Handlebar
3T SPHINX LTD Endurance Aero Track Design (UCI Legal), UD High Modulus Carbon Fiber w/ no Brake Grove, Ø31.8mm x 390mm top & 420mm drop position
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo
Headset
FSA 1.125 Integrated w/ 25mm Aluminum Cone & 2 X 10mm Aluminum Straight Spacer, Felt Tornado Aluminum Top Cap & 2024 Anodized Aluminum Bolt
Seat
Saddle
Felt SL Road Saddle w/ Carbon Fiber Injection Molded Base, Superlight Multi-Density Foam, Embossed Cover & Hollow Cr-Mo rails
Seatpost
Felt TkR Bladed UHC Performance Carbon fiber Airo Micro Adjust, Ø27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 65cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.272 mm | 1.405 mm | 1.3 mm | 1.302 mm | 1.301 mm | 1.303 mm |
| Bottom Bracket Height | 303 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 538 mm | 525 mm | 545 mm | 564 mm | 584 mm | 603 mm |
| Rake | 41 mm | 43 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Stack | 454 mm | 503 mm | 507 mm | 526 mm | 545 mm | 564 mm |
| Reach | 357 mm | 358 mm | 390 mm | 404 mm | 419 mm | 433 mm |
| Head Tube Length | 90 mm | 110 mm | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 374 mm | 385 mm | 385 mm | 385 mm | 385 mm | 385 mm |
| Wheelbase | 916 mm | 903 mm | 923 mm | 943 mm | 962 mm | 982 mm |
| Bottom Bracket Drop | 33 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 665 mm | 748 mm | 767 mm | 785 mm | 805 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tk2 belongs to the Felt Tk2 model. There are 11 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Track bikes average price
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, even if your budget is less than the average, you might still be able to get a top-quality Track bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1599$. Comparing the average cost of a Track bike to this one, you will see that Tk2 price is 6.39% higher.
Track bikes average weight
If we make a quick analysis of the average weight of a Track bike, we get 7.85 kg (17.31 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit lighter than average, Tk2 has a weight of 7.3 kg (16.09 lbs). In other words, this model is 7.53% lighter than the average Track bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Tk2 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
