Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset X3 -
Suspension Rigid -
Drivetrain Single Speed
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Aero Track UltraLite custom butted aluminum, hydroform smooth welded construction, BSA threaded bottom bracket shell, horizontal dropouts with cast steel surfaces
Suspension Fork
Felt Aero Track UHC Performance carbon fiber blades and dropouts, 1.125" aluminum steerer tube
Rear Shock
n/a
Drivetrain
Rear Derailleur
n/a
Front Derailleur
n/a
Shift Levers
n/a
Cassette
15T x 3/32" with lockring
Crank
Felt Track, 48T x 3/32" chainring 144mm BCD, 43cm (650c): 155mm --- 51 - 54cm: 165mm --- 56cm: 167.5mm --- 58 - 61cm: 170mm
Bottom Bracket
Sealed cartridge, BSA threaded, square taper axle, 68 x 110mm
Chain
KMC Z610HX 1-speed 3/32"
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt TkR4, sealed cartridge bearing, 100mm with track nuts, 28H
Rear Hub
Felt TkR4, sealed cartridge bearing, double-threaded fixed / fixed, 120mm with track nuts, 28H
Rims
Felt TkR4, 19mm inner width, 30mm depth
Spokes
2.0mm stainless steel
Tires
Vittoria Zaffiro Slick, 700c x 23c; 43cm (650c): Vittoria Rubino III 650c x 23c
Brakes
Brake Levers
n/a
Cockpit
Stem
Felt SuperLite, ±7° rise, Ø26.0mm, 43cm (650c):80mm; Ø31.8mm, 51cm: 80mm --- 54cm: 90mm --- 56 - 61cm: 100mm
Handlebar
Felt TK:K1,Ø26.0mm, 43cm (650c): 75mm reach, 120mm drop, 360mm; Felt TKR-MSO, Ø31.8mm, 51cm: 360mm -- 54 - 58cm: 390mm --- 61cm: 420mm; Felt
Grips
Felt Gel tape with Felt Bubble-Tech F-Wing bar end plugs
Headset
FSA IS-21 integrated, 1.125" sealed cartridge bearing with aluminum 9mm cone spacer, Felt top cap
Seat
Saddle
Felt SuperLite; 43 (650c): Felt K:1 SuperLite
Seatpost
Felt TkR, Ø27.2mm x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.19 mm | 1.16 mm | 1.17 mm | 1.19 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 566 mm | 582 mm | 598 mm | 619 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 60 mm | 59 mm | 54 mm | 52 mm |
| Stack | 472 mm | 483 mm | 504 mm | 530 mm |
| Reach | 398 mm | 415 mm | 429 mm | 447 mm |
| Top Tube Length | 533 mm | 553 mm | 573 mm | 603 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 505 mm | 525 mm | 545 mm | 570 mm |
| Head Tube Angle | 73 ° | 73.5 ° | 74 ° | 74.5 ° |
| Head Tube Length | 80 mm | 90 mm | 110 mm | 135 mm |
| Chainstay Length | 378 mm | 378 mm | 378 mm | 378 mm |
| Wheelbase | 938 mm | 953 mm | 970 mm | 990 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
TK3 is a Felt Tk3 model. There are 10 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Track bikes average price
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, even though the average price of a Track bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Felt TK3 price was 999$. If we compare this with the average Track bike cost we notice that the price is 50.45% lower.
Track bikes average weight
On a deeper look, we notice that the average weight of a Track bike is 7.85 kg (17.31 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 8.1 kg (17.86 lbs), the TK3 model is slightly heavier than average. In short, the average Track bike weight is 3.18% lower than this one.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on TK3 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
