Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, microSHIFT -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Endurance Road custom 7005 superlight butted smooth welded aluminum, machined threaded BB shell, external cable routing, forged aluminum dropouts & replaceable rear derailleur hanger
Suspension Fork
Felt UHC Performance carbon fiber fork, aluminum steerer tube, crown, & forged dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Sora GS long cage
Front Derailleur
Micro.shift Ø31.8mm clamp
Shift Levers
Micro.shift integrated shifter/brake lever
Cassette
Sunrace R90-series 9 Speed, 12-25T
Crank
FSA Tempo Triple 3pc, 52/42/30T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
FSA 68mm w/ forged Cr-Mo square taper 116mm spindle
Chain
SunRace 9 Speed
Chain Guide
n/a
Pedals
Superlight road platform pedal, toe clips, & straps
Wheels
Front Hub
Felt sealed bearing forged aluminum w/ quick release, 32H
Rear Hub
Felt sealed bearing forged Shimano 9/10 speed compatible freehub w/ quick release, 32H
Rims
Alex R500 aluminum, w/ machined CSW braking surface & wear indicator laced 32H front, 32H rear
Spokes
Stainless steel laced radial front, 3x rear w/ brass nipples
Tires
Felt Speed All Weather, 700c x 25c
Brakes
Brakes
Dual pivot w/ stainless hardware & cartridge brake pads
Brake Levers
Micro.shift short reach integrated w/ top mount levers
Cockpit
Stem
Felt SL 6061 aluminum 3D forged +/-7° rise, Ø31.8mm bar clamp, custom Cr-Mo bolts, 131g; 51cm=80mm, 54cm=80mm, 56cm=90mm, 58cm=100mm, 61cm=110mm
Handlebar
Felt VS 6061 aluminum w/ Felt Variable Shape ergonomic drop, Ø31.8mm, 51cm=400mm, 54cm-56cm=420mm, 58cm-61cm=440mm
Grips
Felt gel tape w/ Felt logos
Headset
FSA 1.125"" integrated, w/ aluminum 25mm conical spacer, 2 X 10mm aluminum headset spacers, 1 x 5mm aluminum headset spacer, Felt Tornado top cap & 2024 anodized aluminum bolt
Seat
Saddle
Felt VS+ road saddle w/ nylon injection molded base, polyurethane foam, embossed cover, & FeC rails
Seatpost
Felt SL 6061 aluminum, Ø27.2mm, 330mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.5 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 583.5 mm | 594.6 mm | 604.9 mm | 614.8 mm | 634.8 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 57 mm | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 543 mm | 564 mm | 583 mm | 602 mm | 622 mm |
| Reach | 376 mm | 385 mm | 389 mm | 393 mm | 407 mm |
| Top Tube Length | 527 mm | 547 mm | 562 mm | 577 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 990 mm | 1001 mm | 1013 mm | 1023 mm | 1044 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 722 mm | 740 mm | 759 mm | 779 mm | 805 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Z100 belongs to the Felt Z100 model. 8 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Felt released this model in 2012, its price was 849$. Comparing this to the average Race bike price, we see that the price is 294.58% lower.
Average weight for Race bikes
On a deeper look, we notice that the average weight of a Race bike is 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Z100 weighs 10.11 kg (22.29 lbs) and is much heavier than the average. In other words, this model is 48.24% heavier than the average Race bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Z100 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
