Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Classic Racing Specific Geometry; UHM Ultra-High Modulus Modular carbon fiber frame with 3K finish; forged dropout & replaceable hanger
Suspension Fork
Felt 1.3 HM High Modulus carbon design with 3K finish; carbon Blades, crown & 1-1/8" steerer; aluminum dropouts with Felt Compression Device
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Ultegra SS Short Cage
Front Derailleur
Shimano Ultegra braze-on, double
Shift Levers
Shimano Ultegra STI, 20 speed
Cassette
Shimano Ultegra 10-Speed Cassette, 11-28T
Crank
Shimano Ultegra Compact, 50/34T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
Shimano Hollowtech-II
Chain
Shimano Ultegra 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Fulcrum Racing 7 20H
Rear Hub
Fulcrum Racing 7 2:1 24H
Rims
Fulcrum Racing 7 w/ custom FELT decals
Spokes
Fulcrum Racing 7 Stainless 2:1
Tires
Vittoria Rubino Pro Folding, 700c x 23c, 150tpi
Brakes
Brakes
Shimano Ultegra Super SLR Dual Pivot w/ Cartridge Brake Shoes
Brake Levers
Shimano Ultegra STI
Cockpit
Stem
Felt 2.1 Adjustable 6061 3D Forged Ø31.8mm w/ +/-(6, 10, or 14) Degree Rise, 51cm=80mm, 54cm=90mm, 56cm=100mm, 58cm-61cm=110mm.
Handlebar
Felt 1.3 2014 Triple Butted Aluminum w/ Aerodynamic Wing Top Section, w/ Ergonomic Drop, Ø31.8mm, 51cm=400mm, 54cm-56cm=420mm, 58cm-61cm=440mm
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo
Headset
FSA 1 1/8 Integrated w/ 20mm Cone & 3 X 7.5mm Spacer Stack
Seat
Saddle
Felt 2.2 Anatomic Road Saddle w/ D2 Double-Density Base, Custom Embossed Cover & Hollow Cr-Mo Rails
Seatpost
Felt 1.2 Carbon Fiber Design, Ø27.2mm, 315mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 583.8 mm | 595 mm | 605.1 mm | 614.9 mm | 634.9 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Top Tube Length | 501.7 mm | 520 mm | 533.5 mm | 547.6 mm | 568.3 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 429 mm | 447 mm | 467 mm | 487 mm | 517 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 985 mm | 996 mm | 1007 mm | 1016 mm | 1037 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 724 mm | 743 mm | 762 mm | 781 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Z4 belongs to the Felt Z4 model. There are 6 bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2999$. In conclusion, this bike price is 11.7% lower than the price of the average Race bike.
Race bikes average weight
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Z4 weighs 7.8 kg (17.2 lbs) and is considerably heavier than the average. To sum up, it’s 14.37% heavier than the average weight of Race bikes.
Z4 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Z4 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Z4 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
