Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Endurance Road UHC Performance MMC Carbon Fiber frame w/ 3KP weave, InsideOut internal molding process, aluminum BB30 shell, internal electric or mechanical cable routing, Carbon Fiber dropouts & replaceable rear derailleur hanger
Suspension Fork
Felt Endurance Road UHC Performance Carbon Fiber monocoque fork; 100% Carbon Fiber ControlTaper 1.125" - 1.5" steerer tube, crown, blades, & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105 braze-on
Shift Levers
Shimano 105 STI
Cassette
Shimano, 12-30t
Crank
FSA Gossamer BB30, 50/34T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
FSA BB30
Chain
FSA Team Issue 10-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt Road
Rear Hub
Felt Road
Rims
Mavic CXP-22
Spokes
Double butted steel
Tires
Vittoria Zaffiro Pro Slick, 700c x 25c
Brakes
Brakes
Dual pivot w/cartridge brake pads
Brake Levers
Shimano 105 STI
Cockpit
Stem
Felt VA 2D forged aluminum w/custom Cr-Mo bolts, +/- 8°/12°/16° adjustable rise, Ø31.8mm bar clamp, 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm.
Handlebar
Felt SL short reach design, 6066 butted aluminum, ergonomic, Ø31.8mm, Drop=118mm, Reach=72 mm, 51cm=400mm, 54cm=420mm, 56cm=420mm, 58cm=440mm, 61cm=440mm
Grips
Felt Gel Tape w/ Felt Logos
Headset
FSA NO.42 1.125" - 1.5" integrated, w/ aluminum 15mm cone spacer, 2 x 10mm PC headset spacer, 1 x 5mm PC headset spacer, Felt compression device & 7075 anodized aluminum bolt
Seat
Saddle
Prologo Kappa EVO, nylon injected base w/light foam & Cr-Mo rails
Seatpost
Felt UHC Performance Carbon Fiber Ø27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 583 mm | 595 mm | 605 mm | 615 mm | 635 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 57 mm | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 543 mm | 563 mm | 582 mm | 602 mm | 622 mm |
| Reach | 375 mm | 386 mm | 390 mm | 393 mm | 407 mm |
| Top Tube Length | 527 mm | 547 mm | 562 mm | 577 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 992 mm | 1004 mm | 1014 mm | 1024 mm | 1044 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 700 | 729 mm | 749 mm | 769 mm | 797 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Z4 is a Felt Z4 model. Felt released 6 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Felt released this model in 2013, its price was 2069$. Comparing the average cost of a Race bike to this one, you will see that Z4 price is 61.91% lower.
Average weight for Race bikes
Race bikes weigh an average of 6.82 kg (15.04 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Z4 weighs 7.69 kg (16.95 lbs) and is considerably heavier than the average. In short, the average Race bike weight is 12.76% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Z4 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Z4 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
