Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Classic Racing Specific Geometry; HM High Modulus Modular carbon fiber frame with 3K Finish; forged dropout & replaceable hanger
Suspension Fork
Felt 1.4 HM High Modulus carbon design with 3K finish, carbon blades, crown & 1-1/8" steerer; aluminum dropouts with Felt Compression Device
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 SS Short Cage
Front Derailleur
Shimano 105 braze-on, double
Shift Levers
Shimano 105 STI, 20-Speed
Cassette
Shimano 10-Speed Cassette, 11-25T
Crank
FSA Omega Compact, 2-PC, Forged Aluminum, 50/34T; 51cm=170mm, 54cm-56cm=172.5cm, 58cm-61cm=175mm
Bottom Bracket
FSA Mega EXO
Chain
Shimano 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt Sealed Forged Aluminum w/ Quick Release, 32H
Rear Hub
Felt Forged Aluminum Sealed Shimano 10, 9, or 8 speed Compatible Cassette w/ Quick Release, 32H
Rims
MAVIC CXP-22N Aluminum Rim w/ Machined UB Control Braking Surface & Wear Indicator laced 3-Cross Rear, Radial 0-Cross Front
Spokes
Stainless Steel w/ Red alloy spoke nipples
Tires
Vittoria Zaffiro Foldable 700c x 25c
Brakes
Brakes
Dual Pivot w/ Cartridge Brake Shoes, Stainless Hardware & Teflon Bushings
Brake Levers
Shimano 105 STI
Cockpit
Stem
Felt 2.1 Adjustable 6061 3D Forged Ø31.8mm w/ +/-(6 or 14) Degree Rise, 51cm=80mm, 54cm=90mm, 56cm=100mm, 58cm-61cm=110mm.
Handlebar
Felt 2.3 6061 Aluminum w/ Relaxed Racing Specific Ergonomic Drop, Ø31.8mm, 51cm=400mm, 54cm=420mm, 56cm-61cm=440mm
Grips
Felt Gel Ribbon Cork Tape w/ Felt 3D Logo
Headset
FSA 1 1/8 Integrated w/ 20mm Cone & 3 X 7.5mm Spacer Stack
Seat
Saddle
Felt 2.2 Anatomic Road Saddle w/ D2 Double-Density Base, Custom Embossed Cover & Hollow Cr-Mo Rails
Seatpost
Felt 1.2 Carbon Fiber Design, Ø27.2mm, 315mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 583.8 mm | 595 mm | 605.1 mm | 614.9 mm | 634.9 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Top Tube Length | 501.7 mm | 520 mm | 533.5 mm | 547.6 mm | 568.3 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 429 mm | 447 mm | 467 mm | 487 mm | 517 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 985 mm | 996 mm | 1007 mm | 1016 mm | 1037 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 724 mm | 743 mm | 762 mm | 781 mm | 807 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Z5 is part of the Felt Z5 model. Felt released 7 bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2010 and its price was 1999$. In conclusion, this bike price is 67.58% lower than the price of the average Race bike.
Race bikes average weight
The average weight for Race bikes is 6.82 kg (15.04 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Felt Z5 it’s weighing 8.21 kg (18.1 lbs). At this weight, is much heavier than average. In conclusion, the average Race bike weighs 20.38% less than Z5.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Z5 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
