Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Endurance Road UHC Performance MMC Carbon Fiber frame w/ 3KP weave, InsideOut internal molding process, aluminum BB30 shell, internal electric or mechanical cable routing, Carbon Fiber dropouts & replaceable rear derailleur hanger
Suspension Fork
Felt Endurance Road UHC Performance Carbon Fiber monocoque fork; 100% Carbon Fiber ControlTaper 1.125" - 1.5" steerer tube, crown, blades, & dropouts
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra braze-on
Shift Levers
Shimano Tiagra STI
Cassette
SunRace, 12-32T
Crank
FSA Omega BB30, 50/34T; 51cm=170mm, 54cm-56cm=172.5mm, 58cm-61cm=175mm
Bottom Bracket
FSA BB30
Chain
SunRace 10-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt Road
Rear Hub
Felt Road
Rims
Mavic CXP-22
Spokes
Stainless steel
Tires
Vittoria Zaffiro Pro Slick, 700c x 25c
Brakes
Brakes
Dual pivot w/cartridge brake pads
Brake Levers
Shimano Tiagra STI
Cockpit
Stem
Felt VA 2D forged aluminum w/custom Cr-Mo bolts, +/- 8°/12°/16° adjustable rise, Ø31.8mm bar clamp, 51cm=90mm, 54cm=100mm, 56cm=100mm, 58cm=110mm, 61cm=120mm.
Handlebar
Felt SL short reach design, 6066 butted aluminum, ergonomic, Ø31.8mm, Drop=118mm, Reach=72 mm, 51cm=400mm, 54cm=420mm, 56cm=420mm, 58cm=440mm, 61cm=440mm
Grips
Felt Gel Tape w/ Felt Logos
Headset
FSA NO.42 1.125" - 1.5" integrated, w/ aluminum 15mm cone spacer, 2 x 10mm PC headset spacer, 1 x 5mm PC headset spacer, Felt compression device & 7075 anodized aluminum bolt
Seat
Saddle
Prologo Kappa EVO, nylon injected base w/light foam & Cr-Mo rails
Seatpost
Felt UHC Performance Carbon Fiber Ø27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 583 mm | 595 mm | 605 mm | 615 mm | 635 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 57 mm | 54 mm | 54 mm | 54 mm | 54 mm |
| Stack | 543 mm | 563 mm | 582 mm | 602 mm | 622 mm |
| Reach | 375 mm | 386 mm | 390 mm | 393 mm | 407 mm |
| Top Tube Length | 527 mm | 547 mm | 562 mm | 577 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 992 mm | 1004 mm | 1014 mm | 1024 mm | 1044 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 700 | 729 mm | 749 mm | 769 mm | 797 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Z5 completes the Felt Z5 model. 7 bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2013 and its price was 1759$. Comparing this to the average Race bike price, we see that the price is 90.45% smaller.
Average weight for Race bikes
Race bikes weigh an average of 6.82 kg (15.04 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 8.3 kg (18.3 lbs), Felt bike is much heavier than average. In short, the average Race bike weight is 21.7% lower than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Z5 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Z5 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
