Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt FIT WOMAN Specific UHC Advanced MMC Carbon Fiber Frame w/ 3KP Weave, External Cable Routing, Forged Aluminum dropouts & replaceable derailleur hanger, 950g
Suspension Fork
Felt FIT WOMAN UHC Performance Carbon Fiber Fork w/ 3KP Weave; Carbon Fiber 1.125 Steerer tube, Crown, Blades, and Aluminum Dropouts, 532g (650C Model: Carbon Dropouts)
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 SS Short Cage
Front Derailleur
Shimano 105 braze-on, double
Shift Levers
Shimano 105 STI, 20-Speed
Cassette
Shimano 105 Cassette, 11-28T
Crank
Shimano 105 Compact, 50/34T (650C Model: 105 53/39T); Petite=165mm, Small & Medium=170mm, Tall=172.5mm
Bottom Bracket
Shimano 105 Hollowtech-II
Chain
Shimano 105 10-Speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt Sealed Forged Aluminum w/ Quick Release, 28H
Rear Hub
Felt Forged Aluminum Sealed Shimano 10, 9, or 8 speed Compatible Cassette w/ Quick Release, 28H
Rims
MAVIC CXP-22S Aluminum Rim w/ Machined UB Control Braking Surface & Wear Indicator laced 3-Cross Rear, Radial 0-Cross Front
Spokes
Stainless Steel Butted 2.0/1.6/2.0mm w/ Aluminum Nipples
Tires
Vittoria Zaffiro Pro, 700c x 23c, 60tpi (650C Model: Vittoria Rubino, 650c x 23c, 60tpi)
Brakes
Brakes
Dual Pivot w/ Cartridge Brake Shoes, Stainless Hardware & Teflon Bushings
Brake Levers
Shimano 105 STI
Cockpit
Stem
Felt SL 6061 Aluminum 3D Forged +/-7° Rise, Ø31.8mm Bar Clamp, custom Cr-Mo bolts, 128g, Petite=70mm, Small=80mm, Medium & Tall=90mm
Handlebar
Felt VS Fit Woman 6061 Aluminum Bar w/ Felt Variable Shape Ergonomic Drop, Ø31.8mm, Petite=380mm, Small=380mm, Medium & Tall=400mm width, 74mm reach, 130mm drop
Grips
Felt FW Fit Woman Soft Touch Tape w/ Fit Woman 3D Logo
Headset
FSA 1.125 Integrated w/ 25mm Aluminum Cone & 2 X 10mm Aluminum Headset Spacer, Felt Aluminum Top Cap & 7075 Anodized Aluminum Bolt
Seat
Saddle
Felt FIT WOMAN Anatomic Carbon Base w/ pressure relief zone, Custom Cover & Custom Cover & Cr-Mo rails
Seatpost
Felt UHC Performance Carbon Fiber Design, Forged Aluminum Head, Twin Side Clamp Bolts, Ø27.2mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Petite | MD | SM | Tall |
|---|---|---|---|---|
| Stack Reach Ratio | 1.401 mm | 1.447 mm | 1.379 mm | 1.461 mm |
| Bottom Bracket Height | 291 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 561 mm | 584 mm | 584 mm | 595 mm |
| Rake | 40 mm | 50 mm | 50 mm | 50 mm |
| Stack | 507 mm | 541 mm | 520 mm | 561 mm |
| Reach | 362 mm | 374 mm | 377 mm | 384 mm |
| Head Tube Length | 130 mm | 140 mm | 120 mm | 160 mm |
| Chainstay Length | 400 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 956 mm | 990 mm | 991 mm | 1001 mm |
| Bottom Bracket Drop | 45 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 675 mm | 726 mm | 702 mm | 749 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
ZW5 is a Felt Zw5 model. 8 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2011 and its price was 2099$. Comparing the average cost of a Race bike to this one, you will see that ZW5 price is 59.6% lower.
Race bikes average weight
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
ZW5 weighs 7.74 kg (17.06 lbs) and is considerably heavier than the average. In short, the average Race bike weight is 13.49% lower than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
ZW5 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on ZW5 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ZW5 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
