Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Felt Fit Woman Road UHC Performance carbon fiber, MMC w/ InsideOut construction, BB30, carbon fiber dropouts, replaceable rear derailleur hanger, electronic compatible internal cable routing
Suspension Fork
Felt Fit Woman Road UHC Performance carbon fiber blades & dropouts w/ 1.125" aluminum steer tube(Petite, Small) Felt Fit Woman Road UHC Performance carbon fiber blades & dropouts w/ ControlTaper 1.125" - 1.5" aluminum steer tube(Medium, Tall)
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano 105 11-speed long cage
Front Derailleur
Shimano 105 11-speed braze-on
Shift Levers
Shimano 105 11-speed STI
Cassette
Shimano 105 11-speed, 11-32T
Crank
Shimano 105 11-speed Petite - Small = 165mm Medium = 170mm Tall = 172.5mm
Bottom Bracket
FSA BB30 w/ 24mm spindle reducers
Chain
Shimano 105 11-speed
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Felt R3, sealed bearing, 24H
Rear Hub
Felt R3, sealed cartridge bearing, 28H, 11-speed
Rims
Felt Fit Woman WRSL3 (tubeless ready), 22mm width, 22mm depth
Spokes
1.8mm stainless steel
Tires
Felt All Weather, 700 x 25c
Brakes
Brakes
Dual pivot caliper
Brake Levers
Shimano 105 11-speed STI
Cockpit
Stem
Felt Fit Woman SuperLite, Ø31.8mm Petite = +/-17° rise, 60mm Small = +/-17° rise, 70mm Medium = +/-7° rise, 80mm Tall = +/-7° rise, 90mm
Handlebar
Felt Fit Woman SuperLite Road, 71mm reach, 118mm drop, Ø31.8mm Petite - Medium = 380mm Tall = 400mm
Grips
Felt SuperGel Tape
Headset
FSA IS2 integrated, 1.125" sealed cartridge bearing w/ Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1x 10mm + 2 x 5mm PC headset spacers, Felt top cap & aluminum bolt(Petite, Small) FSA NO.38/42, 1.125" - 1.5" sealed cartridge bearing w/ Felt VariableHeight Cone Spacers (20mm PC, 4.5mm aluminum), 1x 10mm + 2 x 5mm PC headset spacers, Felt top cap & aluminum bolt (Medium, Tall)
Seat
Saddle
Prologo Kappa EVO PAS DEA
Seatpost
Felt Fit Woman Road UHC Performance carbon fiber, Ø27.2mm, 300mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Petite | SM | MD | Tall |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.47 mm | 1.46 mm | 1.47 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 576 mm | 578 mm | 583 mm | 595 mm |
| Rake | 52 mm | 52 mm | 50 mm | 50 mm |
| Trail | 68 mm | 59 mm | 57 mm | 54 mm |
| Stack | 513 mm | 526 mm | 537 mm | 557 mm |
| Reach | 353 mm | 359 mm | 369 mm | 380 mm |
| Top Tube Length | 491 mm | 508 mm | 521 mm | 541 mm |
| Seat Tube Angle | 75.25 ° | 74.5 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 430 mm | 450 mm | 470 mm | 500 mm |
| Head Tube Angle | 70.25 ° | 71.25 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 406 mm | 406 mm | 413 mm | 413 mm |
| Wheelbase | 970 mm | 973 mm | 986 mm | 998 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 675 mm | 694 mm | 711 mm | 723 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
ZW5 is part of the Felt Zw5 model. 8 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Felt released this model in 2015, its price was 1899$. Doing a quick comparison, we notice that ZW5 price is 76.41% lower than the average cost of a Race bike.
Race bikes average weight
Race bikes have an average weight of 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 8.03 kg (17.7 lbs), the ZW5 model is much heavier than average. In short, the average Race bike weight is 17.74% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
ZW5 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the ZW5 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
