festka Rover SPIRIT Frameset 2024

2024 Road

Estimate price | 6,411$

Weight | 1 kg

Open compare Use advisor

Bike details

Overview

Key information split into simple groups.

Frame summary

Category
- Road
- |
- Gravel
Frame Carbon
Wheels 700c
Groupset RED AXS
Suspension Rigid
Drivetrain Electronic

Sizing

Recommended size guide.

XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Suspension Fork

Columbus Futura Gravel 1 ¼"

Drivetrain

Shift Levers

mechanical, EPS, Di2, eTap,

Bottom Bracket

PF 86,5 / 41 mm

Seat

Seatpost

31,6 mm

Fit data

Geometry

Numbers for sizing and ride feel.

Size	XXS	XS	SM	MD	LG	XL	XXL
Stack Reach Ratio	1.417 mm	1.411 mm	1.468 mm	1.496 mm	1.506 mm	1.529 mm	1.525 mm
Bottom Bracket Height	275 mm	275 mm	275 mm	275 mm	275 mm	275 mm	275 mm
Front Center	577 mm	585 mm	588 mm	594 mm	599 mm	620 mm	640 mm
Rake	51 mm	50 mm	51 mm	50 mm	50 mm	50 mm	50 mm
Trail	79 mm	69 mm	66 mm	59 mm	56 mm	56 mm	56 mm
Stack	506 mm	525 mm	546 mm	570 mm	583 mm	610 mm	630 mm
Reach	357 mm	372 mm	372 mm	381 mm	387 mm	399 mm	413 mm
Top Tube Length	500 mm	520 mm	530 mm	545 mm	560 mm	580 mm	600 mm
Seat Tube Angle	74.5 °	74.5 °	74 °	74 °	73.5 °	73.5 °	73.5 °
Seat Tube Length	419 mm	440 mm	470 mm	500 mm	515 mm	540 mm	560 mm
Head Tube Angle	69.5 °	71 °	71.5 °	72.5 °	73 °	73 °	73 °
Head Tube Length	97 mm	111 mm	131 mm	153 mm	165 mm	193 mm	214 mm
Chainstay Length	425 mm	425 mm	425 mm	425 mm	425 mm	425 mm	425 mm
Wheelbase	991 mm	999 mm	1002 mm	1008 mm	1013 mm	1034 mm	1054 mm
Bottom Bracket Drop	74 mm	74 mm	74 mm	74 mm	74 mm	74 mm	74 mm
Standover Height	737 mm	756 mm	781 mm	807 mm	821 mm	846 mm	866 mm
Wheels	700	700	700	700	700	700	700
Rider Min Height	157 cm	165 cm	171 cm	177 cm	183 cm	188 cm	194 cm
Rider Max Height	167 cm	173 cm	179 cm	185 cm	191 cm	197 cm	204 cm
