Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari DFA2 compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses
Suspension Fork
Fezzari FD2 Carbon Fiber Thru Axle Fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora R3000 GS, 9 speed
Front Derailleur
Shimano Sora R3000, clamp on, 2 speed, new longer actuation arm for smoother easier shifting
Shift Levers
Shimano Sora R3000 Dual Control, 2x9 speed
Cassette
Sunrace CSM90, 9 speed, 11x34t, extra wide range for easier hill climbing without sacrificing high gear
Crank
FSA Vero Pro Adventure, JIS, anodized black
Bottom Bracket
FSA BB7420, JIS, heavy duty
Chain
KMC X9 NP/GY, 9 speed
Pedals
N/A
Wheels
Front Hub
Alex, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rear Hub
Alex, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rims
Alex ATD-490, 700c, alloy double wall, 32-hole, Tubeless Ready
Spokes
2.0mm (14g) stainless
Tires
Maxxis Re-Fuse, 700x32c Tubeless Ready
Brakes
Brakes
Tektro MD-C550 Dual piston mechanical disc brake
Brake Levers
Shimano Sora Dual Control with STI precision, improved comfortable anatomic design, reach adjust
Cockpit
Stem
Fezzari 3D forged 7500 series alloy, 31.8mm 4-bolt bar clamp (rise and length customizable through 23-Point Custom Setup)
Handlebar
Fezzari alloy, double butted 31.8mm, blast black (width customizable through 23-Point Custom Setup)
Headset
FSA Orbit 1.5 ZS NO.57E
Seat
Saddle
Selle Italia Model X
Seatpost
Fezzari Racing Design XrT Dual Bolt Carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.55 mm | 1.54 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 582 mm | 603 mm | 619 mm | 645 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 72 mm | 67 mm | 67 mm |
| Stack | 543 mm | 562 mm | 585 mm | 604 mm |
| Reach | 348 mm | 362 mm | 381 mm | 401 mm |
| Top Tube Length | 505 mm | 525 mm | 545 mm | 575 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1002 mm | 1024 mm | 1040 mm | 1066 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 762 mm | 782 mm | 787 mm | 793 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Catania is part of the Fezzari Catania model. Fezzari released 4 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Fezzari released this model in 2021, its price was 1199$. If we compare this with the average Endurance bike cost we notice that the price is 95.66% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Catania bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Catania comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
