Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Murdock compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses
Suspension Fork
Fezzari Hybrid Carbon Fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Apex 1, Wide Range
Front Derailleur
N/A
Shift Levers
SRAM Apex 1x11 Flat Bar Shifter, Wide Range
Cassette
SRAM PG-1130 11-42t, Wide Range
Crank
SRAM Apex 1x
Bottom Bracket
SRAM GXP English, 68mm
Chain
SRAM PC-1110
Pedals
N/A
Wheels
Front Hub
Bear Pawls, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rear Hub
Bear Pawls, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rims
WTB ST i21 TCS 2.0, 32 hole, Disc only, Tubeless ready
Spokes
2.0mm (14g) stainless
Tires
Maxxis Refuse 700x40c Tubeless Ready, Kevlar lined puncture protection
Brakes
Brakes
SRAM Level, SRAM Centerline 160mm/160mm F/R Rotors
Brake Levers
SRAM Level
Cockpit
Stem
Fezzari 3D forged alloy, 31.8mm 4-bolt bar clamp (rise and length customizable through 23-Point Custom Setup)
Handlebar
Fezzari alloy, double butted 31.8mm, blast black (width customizable through 23-Point Custom Setup)
Headset
FSA Orbit 1.5 ZS NO.57E
Seat
Saddle
Selle Italia Model X Super Flow
Seatpost
Fezzari Racing Design XrT Dual Bolt Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.5 mm | 1.52 mm | 1.49 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 619 mm | 645 mm | 667 mm | 687 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 70 mm | 70 mm | 68 mm | 70 mm |
| Stack | 589 mm | 608 mm | 632 mm | 646 mm |
| Reach | 385 mm | 405 mm | 417 mm | 434 mm |
| Top Tube Length | 549 mm | 579 mm | 599 mm | 619 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 165 mm | 185 mm | 210 mm | 225 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1044 mm | 1070 mm | 1092 mm | 1112 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 767 mm | 789 mm | 794 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Murdock APEX 1X is part of the Fezzari Murdock model. There are 8 bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Fezzari Murdock APEX 1X price was 1199$. Comparing this to the average Commuter bike price, we see that the price is 57.35% more expensive.
Murdock APEX 1X components
Fork material
Murdock APEX 1X has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Fezzari Murdock APEX 1X 2022, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fezzari Murdock APEX 1X is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
