Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery 500 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminium, internal cable routing, international disc brake standard
Suspension Fork
SR Suntour NEX RL, 9 mm QR, 63 mm travel
Drivetrain
Rear Derailleur
Shimano Deore XT 786, 10-speed
Shift Levers
Shimano Deore M6000
Crank
1x
Bottom Bracket
BSA, threaded
Wheels
Rims
Schürmann Yak19 622-19, Shimano TX50 CL, 9 mm, QR
Tires
Schwalbe Delta Cruiser 700x40c Plus
Brakes
Brakes
Shimano M315, 180 mm / 160 mm
Cockpit
Stem
aluminium, 31,8 mm, 90 mm
Handlebar
aluminium, riserbar, 700mm
Seat
Seatpost
Sport components SP-DC1
Motor & Battery
Motor
Bosch Performance CX, 75 Nm, 250 W, 50-300% support power
Battery
500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.53 mm | 1.6 mm | 1.74 mm |
| Front Center | 624 mm | 645 mm | 651 mm | 659 mm |
| Rake | 45 mm | 55 mm | 55 mm | 55 mm |
| Trail | 73 mm | 66 mm | 64 mm | 64 mm |
| Stack | 624 mm | 608 mm | 637 mm | 684 mm |
| Reach | 378 mm | 398 mm | 399 mm | 393 mm |
| Top Tube Length | 569 mm | 579 mm | 594 mm | 609 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 150 mm | 135 mm | 170 mm | 220 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1091 mm | 1112 mm | 1119 mm | 1128 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AVENTURA² Pro is a Focus E Aventura2 model. Focus launched 20 e-bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid e-bikes
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
AVENTURA² Pro components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The AVENTURA² Pro 2018 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Focus AVENTURA² Pro has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Focus AVENTURA² Pro e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
