Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset XT -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm
Suspension Fork
FOX 36 Float Factory 29, Grip 2, 110 x 15 mm, 44 mm rake
Rear Shock
FOX Float X Performance, 210/55 mm, hardware: 25,0 x 8.0, no Bushing
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
Samox EC40 ISIS
Bottom Bracket
Integrated in Drive Unit
Chain
Shimano SLX CN-M7100, 12-speed
Wheels
Rims
DT SWISS H1900, 30-622, 15x110 mm / 12x148 mm
Tires
MAXXIS Minion DHF, 2.6 EXO+ / MAXXIS MINION DHRII, 2,6 EXO+ / MAXXIS Minion DHF, 2.6 EXO+ / MAXXIS MINION DHRII, 2,6 EXO+
Brakes
Brakes
Shimano XT M8120, 4 piston / Shimano XT M8120, 4 piston
Cockpit
Stem
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
Handlebar
RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8°
Grips
RaceFace Getta Grip
Headset
ACROS ZS56/ZS60 (ICR), FOCUS C.I.S. Integrated angle headset
Seat
Saddle
Proxim W350
Seatpost
Post Moderne dropper post PM-214, 34.9 mm
Motor & Battery
Motor
Bosch Performance CX Smart, 85 Nm, 250 W
Remote
Bosch LED Remote + Kiox 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.339 mm | 1.307 mm | 1.266 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 761 mm | 791 mm | 824 mm | 863 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 130 mm | 130 mm | 130 mm | 130 mm |
| Stack | 616 mm | 616 mm | 634 mm | 652 mm |
| Reach | 430 mm | 460 mm | 485 mm | 515 mm |
| Top Tube Length | 578 mm | 608 mm | 637 mm | 672 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1210 mm | 1240 mm | 1273 mm | 1312 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 800 mm | 800 mm | 800 mm | 800 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
