Focus JAM 6.8 2024
2024 Mountain
Estimate price |
3,489$
Weight | 16 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Revelation RC
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. Gen2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Suspension Fork
Rock Shox Revelation RC 29 Boost, DebonAir, 110x15 mm, 46 mm rake
Rear Shock
RockShox Deluxe Select, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210 Eagle, 12-speed
Crank
SRAM NX Eagle
Bottom Bracket
BSA
Chain
SRAM SX Eagle, 12-speed
Wheels
Front Hub
Shimano TC500, 15x110 mm
Rear Hub
Shimano Deore, 12x148 mm
Rims
RODI TRYP30, 30-622
Spokes
Niro, black
Tires
Maxxis Minion DHF, EXO, 63-622 / Maxxis Minion DHF, EXO, 63-622
Brakes
Brakes
Magura MT Trail, front: 4-piston / rear: 2-piston / Magura MT Trail, front: 4-piston / rear: 2-piston
Cockpit
Stem
FOCUS C.I.S. 50 mm, 0°, 35 mm, aluminium
Handlebar
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
Grips
FOCUS Locker SL
Headset
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
Seat
Saddle
Selle Royal Groove SRX
Seatpost
Post Moderne dropper post PM-171, 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.36 mm | 1.313 mm | 1.271 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 733 mm | 767 mm | 805 mm | 844 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 129 mm | 130 mm | 130 mm | 129 mm |
| Stack | 603 mm | 612 mm | 630 mm | 648 mm |
| Reach | 420 mm | 450 mm | 480 mm | 510 mm |
| Top Tube Length | 570 mm | 603 mm | 637 mm | 672 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1166 mm | 1200 mm | 1238 mm | 1277 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 766 mm | 766 mm | 766 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
