Focus JARIFA² 6.9 2024
2024 E-bike
Estimate price |
5,350$
Weight | 24.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour RAIDON
-
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch 625 IntubeWh,Bosch PowerTube Li-Ion 36 V / 20,1 Ah (750 Wh) -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, post mount 180 mm
Suspension Fork
SR Suntour Raidon 34 LOR AIR, 110x15 mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore CS-M6100, 12-speed
Crank
FSA CK-320, aluminium
Bottom Bracket
Integrated in Drive Unit
Chain
Shimano Deore CN-M6100, 12-speed
Wheels
Front Hub
Shimano TC500, 15x110 mm
Rear Hub
Shimano TC500, 148 x 12 mm
Rims
Shimano WH-MT501, 24-622, 15x110 mm / 12x148 mm
Tires
Schwalbe Smart Sam, 57-584 / Schwalbe Smart Sam, 57-584,Schwalbe Smart Sam 2.25, 57-622 / Schwalbe Smart Sam 2.25, 57-622
Brakes
Brakes
Shimano MT420 / Shimano MT420
Cockpit
Stem
FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium
Handlebar
Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm
Grips
Herrmans Click
Headset
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
Seat
Saddle
Selle Royal Vivo
Seatpost
Aluminium, 31.6 mm
Motor & Battery
Motor
Bosch Performance CX Smart, 85 Nm, 250 W
Battery
Bosch 625 IntubeWh,Bosch PowerTube Li-Ion 36 V / 20,1 Ah (750 Wh)
Remote
Bosch LED Remote + Kiox 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.531 mm | 1.566 mm | 1.498 mm | 1.451 mm | 1.43 mm |
| Bottom Bracket Height | 329 mm | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 646 mm | 712 mm | 717 mm | 746 mm | 748 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 139 mm | 105 mm | 101 mm | 95 mm | 121 mm |
| Stack | 597 mm | 642 mm | 644 mm | 653 mm | 672 mm |
| Reach | 390 mm | 410 mm | 430 mm | 450 mm | 470 mm |
| Top Tube Length | 561 mm | 594 mm | 615 mm | 638 mm | 662 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 460 mm | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1102 mm | 1175 mm | 1180 mm | 1209 mm | 1211 mm |
| Bottom Bracket Drop | 45 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 766 mm | 808 mm | 820 mm | 838 mm | 860 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
