Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 180mm -
Travel Rear 170mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. Gen2, 148x12 mm thru axle, internal cable routing, post mount 203 mm
Suspension Fork
FOX 38 Factory Float 29, Grip 2, E-Bike+, 110x15 mm, 44 mm rake
Rear Shock
FOX DHX Performance Coil, 230/65 mm, hardware: 20,0 x 8.0 mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed
Crank
Samox EC40 ISIS
Bottom Bracket
Integrated in Drive Unit
Chain
Shimano SLX CN-M7100, 12-speed
Wheels
Front Hub
Novatec D041, 15x110 mm thru axle
Rear Hub
Novatec D462, 12x148 mm
Rims
RaceFace AR30 Offset
Spokes
Niro, black
Tires
Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622 / Schwalbe Magic Mary, 2.6 Super Gravity Soft, 65-622 / Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622 / Schwalbe Magic Mary, 2.6 Super Gravity Soft, 65-622
Brakes
Brakes
Shimano XT M8120, 4 piston / Shimano XT M8120, 4 piston
Cockpit
Stem
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
Handlebar
RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8°
Grips
RaceFace Getta Grip
Headset
ACROS ZS56/ZS60 (ICR), FOCUS C.I.S. Integrated angle headset
Seat
Saddle
Proxim W350
Seatpost
Post Moderne dropper post PM-214, 34.9 mm
Motor & Battery
Motor
Bosch Performance CX Smart, 85 Nm, 250 W
Remote
Bosch LED Remote + Kiox 300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.416 mm | 1.326 mm | 1.295 mm | 1.255 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 790 mm | 820 mm | 854 mm | 888 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 138 mm | 138 mm | 138 mm | 143 mm |
| Stack | 623 mm | 623 mm | 641 mm | 659 mm |
| Reach | 440 mm | 470 mm | 495 mm | 525 mm |
| Top Tube Length | 578 mm | 608 mm | 637 mm | 671 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1239 mm | 1269 mm | 1303 mm | 1337 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 803 mm | 799 mm | 799 mm | 799 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
