Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Elite Float 34
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Formula Cura 4 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Forestal Alpha Box Carbon Down-Country 29" DC120 Monocoque construction | Internal Storage | 120mm Travel
Suspension Fork
FOX 34 Performance Elite 130mm 2025, 34 FLOAT | Performance Elite Series | 29" | Travel: 130mm | GRIP X2 | Offset: 44mm | Kabolt: 15x110 | Gloss Black - Standard Logo
Rear Shock
FOX Float Performance Elite Metric 210x50mm | Performance Elite | Custom tune | Travel: 120mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12 Speed | X-Actuation | Long cage | Colour: Lunar Grey
Shift Levers
SRAM GX Eagle 12 Speed | X-Actuation | Colour: Lunar Grey
Cassette
SRAM Eagle XG-1275 10-52T | 12 Speed | XD Driver Body | Colour: Black
Crank
SRAM GX Eagle DUB | Lenght 170mm | 34T | Colour: Lunar Grey
Chain
SRAM GX Eagle 12 Speed | Powerlock | Colour: Silver-Black
Wheels
Rims
Front: DT Swiss XM 1700 Alloy 29" 15x110 Boost | 350 hub | 6 bolt | Inner width 30mm, Rear: DT Swiss XM 1700 Alloy 29" 12x148 Boost | 350 hub | 6 bolt | SRAM XD | Ratchet 36 SL | Inner width 30mm
Tires
Front: Schwalbe Nobby Nick 2.40 Super Ground - Soft Super Ground casing | Soft (orange line) compound | 29x2.40, Rear: Schwalbe Nobby Nick 2.40 Super Ground - Soft Super Trail casing | Speedgrip (blue line) compound | 29x2.40
Brakes
Brakes
Formula Cura 4
Cockpit
Stem
Forestal Oxydon 45mm ? 31.8mm | 7075 Heavy duty Aluminium
Handlebar
Forestal Oxydon C 780mm ? 31.8mm | Upsweep 4° | Backsweep 6° | Rise 15mm | Toray T700 & T800 Carbon
Grips
Ergon GA20 Ergonomic lightweight with bar plugs | Plastic ring grey logo
Headset
Acros Integrated ZS 56 Top | ZS 56 Bottom | Internal cable routing | Stainless steel bearings | Custom top cap
Seat
Saddle
Fizik Terra Ridon Fibre reinforced nylon | S-alloy rails | 230g | 140mm
Seatpost
OneUp V3 ? 31.6mm | Length 150-160mm size S/M | 170-180mm size L, XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.3 mm | 1.263 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm |
| Front Center | 722 mm | 751 mm | 795 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 123 mm | 123 mm | 109 mm |
| Stack | 602 mm | 611 mm | 625 mm |
| Reach | 445 mm | 470 mm | 495 mm |
| Top Tube Length | 595 mm | 620 mm | 650 |
| Seat Tube Angle | 76 ° | 76 ° | 75.5 ° |
| Seat Tube Length | 415 mm | 455 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1168 mm | 1197 mm | 1241 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm |
| Wheels | 29" | 29" | 29" |
