Forestal e-Cygnus Diode 2025
2025 E-bike
Estimate price |
13,145$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox SID Ultimate
-
Groupset X0 Eagle Transmission -
Suspension Full -
Motor Bosch 250W 55Nm mid-drive -
Battery Bosch Compact PowerTube 400wh Range Extender Compatible: Bosch PowerMore 250wh | 180° Reversed cable -
Drivetrain 1 × 12 Electronic -
Brakes Formula Cura Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Forestal Alpha Box Carbon Bosch SX 29" e-DC120 Monocoque construction | Bosch SX System | 120mm Travel
Suspension Fork
RockShox Sid Ultimate 29" 120mm Charger Race Day 2 | Tapered | Boost 15x110 | Maxle Stealth | Offset: 44mm | 3 pos. Low-Speed Compression | Gloss Black
Rear Shock
RockShox Sid Luxe Ultimate Metric 210x50 | Custom tune | Debonair | Travel: 120mm | Extl. Rebound | 2 position (Open / Firm) | Compression adjust | Black
Drivetrain
Rear Derailleur
SRAM X0 AXS T-Type 12 Speed | Direct mount | Long cage | Colour: Black
Shift Levers
SRAM AXS POD Ultimate Controller 12 Speed | MMX | Colour: Black | POD interchangeable buttons
Cassette
SRAM X0 T-Type XS-1295 10-52T | 12 Speed | XD Drive Body | Colour: Black
Crank
Praxis e-Crank Carbon XC/Trail Q-Factor 180mm | ISIS Drive | Length 165mm
Bottom Bracket
Bosch, press-fit
Chain
SRAM X0 Eagle T-Type 12 Speed | Powerlock | Colour: Black | T-Type Flattop
Wheels
Rims
Front: DT Swiss XM 1700 Alloy 29" 15x110 Boost | 350 hub | 6 bolt | Inner width 30mm, Rear: 15x110 Boost | 350 hub | 6 bolt | Inner width 30mm 12x148 Boost | 350 hub | 6 bolt | SRAM XD | Ratchet 36 SL | Inner width 30mm
Tires
Front: Maxxis Minion DHF 2.35 Tubeless Ready | Triple Compound | Puncture resistant wall | 29x2.35, Rear: Maxxis High Roller II 2.35 Tubeless Ready | Triple Compound | Puncture resistant wall | 29x2.35
Brakes
Brakes
Formula Cura 2
Cockpit
Stem
Integrated with Forestal Oxydon C Handlebar Length: 60mm | 0º
Handlebar
Forestal Oxydon C 780mm Integrated Carbon fibre | Upsweep 6° | Backsweep 7° | Rise 8mm
Grips
Ergon GA20 Ergonomic lightweight with bar plugs | Plastic ring grey logo
Headset
Acros Integrated Integrated with Forestal Oxydon C Handlebar
Seat
Saddle
Fizik Terra Ridon Fibre reinforced nylon | S-alloy rails | 230g | 140mm
Seatpost
OneUp V3 ? 31.6mm | Length 150-160mm size S/M | 170-180mm size L, XL
Motor & Battery
Motor
Bosch SX Performance Line Wide | 250W | 55Nm | IP67 | 1.95Kg
Battery
Bosch Compact PowerTube 400wh Range Extender Compatible: Bosch PowerMore 250wh | 180° Reversed cable
Remote
Bosch Mini Remote Mini Remote & System Controller
