Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 18" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 T6 heat treated Aluminium alloy, seat tube 255mm
Suspension Fork
6061 T6 heat treated aluminium alloy
Drivetrain
Cassette
ATA, standard ISO thread, 18t, 4 prong removal, chrome plated/brown
Crank
Frog Bikes Patented, 102mm, Aluminium straight arm cranks, 32T chainring, Black
Bottom Bracket
Thun, square taper, 68/107.5, cartridge bearings
Chain
KMC, single speed
Pedals
Resin platform, 9/16" thread, w/reflectors
Wheels
Front Hub
Quando, aluminium, sealed hub, 5mm allen bolt internal fixing, 16 hole
Rear Hub
Quando, aluminium, sealed hub, standard freewheel thread and 5mm allen bolt internal fixing, 16 hole, drive side chain tensioner
Rims
Aluminium, 18", double wall, machined braking surface
Tires
Kenda K1047, 16"x1.5", Hybrid, (ETRTO/ISO: 38-305)
Brakes
Brakes
Tektro 836AL, Aluminium, linear pull
Brake Levers
Tektro JL510, Aluminium, easy reach
Cockpit
Stem
Aluminium, 1"1/8, 38mm, 4 bolt clamp
Handlebar
Aluminium, 30mm riser bar, 440mm
Headset
Neco, 1"1/8, threadless, safety steering stop, Frog Bikes top cap
Seat
Saddle
Frog Bikes child-specific saddle (small), steel rails
Fit data
Geometry
