Fuji Absolute 1.3 2024
2024 Urban
Estimate price |
1,049$
Weight | 11.86 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT R9 -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom butted alloy
Suspension Fork
Fuji C10 carbon
Drivetrain
Rear Derailleur
microSHIFT R9
Front Derailleur
microSHIFT R9
Shift Levers
microSHIFT R9, 2 x 9-speed
Cassette
microSHIFT, 11-34T
Crank
Prowheel Ounce 521, 50/34T
Bottom Bracket
Sealed cartridge bearing
Chain
KMC X9
Pedals
Alloy platform
Wheels
Rims
Alex double wall rims 32h, Shimano OR Formula center lock hubs, stainless spokes
Tires
Vittoria Urbano, 700 x 35c
Brakes
Brakes
C-STAR Rush, hydraulic disc, 160mm rotors
Brake Levers
C-STAR Rush, hydraulic disc
Cockpit
Stem
3D-forged alloy, +/- 6°, 31.8mm
Handlebar
Alloy, 18mm rise, 6° backsweep
Grips
Velo comfort sport
Headset
1-1/8" semi-integrated
Seat
Saddle
Selle Royal Vivo Ergo
Seatpost
Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.347 mm | 1.423 mm | 1.476 mm | 1.445 mm | 1.458 mm |
| Front Center | 622 mm | 622 mm | 627 mm | 627 mm | 679 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 87 mm | 78 mm | 72 mm | 98 mm | 73 mm |
| Stack | 528 mm | 555 mm | 583 mm | 601 mm | 630 mm |
| Reach | 392 mm | 390 mm | 395 mm | 416 mm | 432 mm |
| Top Tube Length | 533 mm | 549 mm | 575 mm | 600 mm | 625 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm | 584 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 145 mm | 170 mm | 190 mm | 220 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1055 mm | 1055 mm | 1060 mm | 1060 mm | 1112 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 728 mm | 765 mm | 802 mm | 835 mm | 873 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
