Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 180mm -
Travel Rear 160mm -
Fork RockShox ZEB Select+
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes TRP Trail EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 160mm
Suspension Fork
RockShox ZEB Select+ 27.5 DebonAir, tapered alloy steerer, Boost 110x15mm, 180mm
Rear Shock
RockShox Super Deluxe Coil Select+
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle, 1 x 12-speed
Cassette
SRAM XG-1275, 10-52T
Crank
Truvativ Descendant, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM GX Eagle
Wheels
Rims
WTB Speedterra i30 wheelset, 32H
Tires
Maxxis Assegai, 27.5" x 2.50" WT, 3C Maxx Terra, EXO+, 120tpi, Tubeless Ready, folding, Maxxis Minion DHR II, 27.5" x 2.40", 3C Maxx Terra, EXO+, 120tpi, Tubeless Ready, folding
Brakes
Brakes
TRP Trail EVO, 203/180mm rotors
Brake Levers
TRP Trail EVO
Cockpit
Stem
Race Face Aeffect R, alloy, +0 degree rise
Handlebar
Race Face Aeffect R Riser Bar, alloy, 20mm rise, 780mm
Grips
Ergon GA20, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Fizik Alpaca Terra X5
Seatpost
Crankbrothers Highline 3 dropper, 31.6mm, 15" - 125mm travel, 17, 19"- 150mm travel, 21" - 170mm travel, Highline Premium Ball Socket Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.341 mm | 1.302 mm | 1.267 mm | 1.235 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 785 mm | 809 mm | 834 mm | 858 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 603.5 mm | 612 mm | 621 mm | 630 mm |
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Top Tube Length | 584 mm | 611 mm | 639 mm | 661 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1210 mm | 1234 mm | 1259 mm | 1283 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 759 mm | 769 mm | 773 mm | 775 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
