Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 180mm -
Travel Rear 160mm -
Fork RockShox Yari RC
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes TRP Slate EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy front and rear triangle, Enduro Max sealed cartridge bearings, MLink patented suspension system, Boost 148x12mm, 160mm
Suspension Fork
RockShox Yari RC 27.5 DebonAir, tapered alloy steerer, Boost 110x15mm, 180mm
Rear Shock
RockShox Super Deluxe Coil Select
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 1 x 12-speed
Cassette
SRAM PG-1210, 11-50T
Crank
SRAM SX Eagle, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM SX Eagle
Wheels
Rims
WTB ST i30 TCS 2.0 32H, Formula DC-711 front hub, DC-3248 rear hub, DT Swiss Industry stainless spokes
Tires
Maxxis Assegai, 27.5" x 2.50" WT, 60tpi, EXO, Tubeless Ready, folding, Maxxis Minion DHR II, 27.5" x 2.40", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
TRP Slate EVO, 203/180mm rotors
Brake Levers
TRP Slate EVO
Cockpit
Stem
TranzX, alloy, +0 degree rise
Handlebar
TranzX Riser Bar, alloy, 20mm rise, 780mm
Grips
WTB Waffel, Lock on
Headset
FSA 1 1/8" - 1.5", sealed cartridge bearings
Seat
Saddle
Selle Italia X3 Boost
Seatpost
TranzX JD-YSP18P, 31.6mm, 15" - 130mm travel, 17, 19, 21" - 150mm travel, PLQ Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.341 mm | 1.302 mm | 1.267 mm | 1.235 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 785 mm | 809 mm | 834 mm | 858 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 603.5 mm | 612 mm | 621 mm | 630 mm |
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Top Tube Length | 584 mm | 611 mm | 639 mm | 661 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 458 mm | 495 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1210 mm | 1234 mm | 1259 mm | 1283 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 759 mm | 769 mm | 773 mm | 775 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
