Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Fork RockShox 35 Silver
-
Groupset NX Eagle, SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A6-SL super-butted alloy, smooth welds, Boost 148x12mm
Suspension Fork
RockShox 35 Silver TK 29 Solo Air, tapered alloy steerer, Boost 110x15mm, 130mm
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM SX Eagle, 1 x 12-speed
Cassette
SRAM PG-1210, 11-50T
Crank
SRAM SX Eagle, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM SX Eagle
Wheels
Rims
WTB ST i30 TCS 2.0 32H rims, Formula DC-711 front hub, DC-3248 rear hub, DT Swiss Industry spokes
Tires
Maxxis Minion DHF, 29" x 2.50" WT, 60tpi, EXO, Tubeless Ready, folding, Maxxis Aggressor, 29" x 2.30", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Tetro HD-M745, 180mm rotors
Brake Levers
Tetro HD-M745
Cockpit
Stem
Race Face Ride, alloy, +6° rise
Handlebar
Race Face Ride Riser Bar, alloy, 10mm rise, 760mm
Grips
WTB Waffel Lock on
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seat
Saddle
Selle Italia X3 Boost
Seatpost
TranzX JD-YSP18P, 30.9mm, 15" - 130mm travel, 17, 19, 21" - 150mm travel, PLQ Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.495 mm | 1.438 mm | 1.36 mm | 1.316 mm | 1.288 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 698 mm | 724 mm | 749 mm | 775 mm | 805 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm | 91 mm |
| Stack | 612 mm | 621.2 mm | 621.2 mm | 630.5 mm | 639.7 mm |
| Reach | 409.5 mm | 431.9 mm | 456.9 mm | 479.2 mm | 496.6 mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | 660 mm | 680 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 465 mm | 513 mm | 543 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1125 mm | 1152 mm | 1177 mm | 1203 mm | 1233 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 633 mm | 669 mm | 685 mm | 687 mm | 709 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
